| Maximum lift height (A) | 3855 mm 151.8 in. |
| Lift capacity at full height | Measured at pivot (U) 3746 lb 1699 kg |
| Boom breakout force | Measured at pivot (Y) 2677 kgf 5902 lbf |
| Bucket rollback force capacity | At ground-level line (ZZ) 3059 kgf 6744 lbf |
| Clearance at full height - bucket dumped (C) | 2826 mm 111.3 in. |
| Dump angle, degrees (E) | -7 degree (angle) |
| Rollback angle, degrees (G) | 42 degree (angle) |
| Model | 6105R/6115R/6125R |
| Front tire | 16.9R24 |
| Rear tire | 18.4R38 |
| Front axle configuration | MFWD w/ Limited Slip Differential |
| Wheelbase | 2580 mm 101.6 in. |
| Pump capacity | 114 L/min 30.1 gpm |
| Rated pressure | 2901 psi 200 bar |
| Base weight | 1356.8 kg |
| Leveling configuration | Mechanical Self Leveling (MSL) |
| Bucket used | Materials 73 in. Materials 1850 mm |
| Bucket weight | 620 lb 281 kg |
| Lift capacity at 59 in. (1500 mm) | Measured at pivot (W) 2187 kg 4822 lb Measured at 800 mm ahead of pivot (X) 2090 kg 4608 lb |
| Dimensions | Maximum lift height (A) 3855 mm 151.8 in. At full height - bucket level(B) 3661 mm 144.1 in. At full height - bucket dumped (C) 2826 mm 111.3 in. |
| Overall length (I+F), ft (m) | 5 m 16.4 ft |
| Digging depth (H) | 31 mm 1.2 in. |
| Reach | At maximum height (D) 800 mm 31.5 in. At ground level - bucket level (F) 2422 mm 95.4 in. |
| Bucket angle | Dump angle, degrees (E) -7 degree (angle) Rollback angle, degrees (G) 42 degree (angle) Dump angle, ground -95 degree (angle) |
| Cycle times | Loader raise, seconds 2.3 seconds Loader lower, seconds 1.9 seconds Bucket dump, seconds 1.4 seconds Bucket rollback, seconds 1.4 seconds |
Inventory moves fast. Call your nearest store to confirm this unit is still here and get the current price.
Yes. Send us the make, model, year and hours of your machine and we will apply the equity.
Often yes, through John Deere Financial and outside lenders depending on the machine. Subject to approved credit and to change.
Yes. We move equipment between all 17 of our Indiana and Ohio dealerships.
Tell us what you want to know about the John Deere H310.
