| Maximum lift height (A) | 4480 mm 176 in. |
| Lift capacity at full height | Measured at pivot (U) 2453 kg 5408 lb |
| Boom breakout force | Measured at pivot (Y) 3411 kgf 7520 lbf |
| Bucket rollback force capacity | At ground-level line (ZZ) 4336 kgf 9559 lbf |
| Clearance at full height - bucket dumped (C) | 3465 mm 136 in. |
| Dump angle, degrees (E) | 60 degree (angle) |
| Rollback angle, degrees (G) | 48 degree (angle) |
| Model | 6175R/M, 6195R/M, 6215R |
| Front tire | 600/70R28 |
| Rear tire | 650/85R38 |
| Front axle configuration | MFWD |
| Wheelbase | 2800 mm 110 in. |
| Pump capacity | 114 L/min 30.1 gpm |
| Rated pressure | 200 bar 2900 psi |
| Base weight | 1808.2 kg |
| Leveling configuration | Mechanical Self Leveling (MSL) |
| Bucket used | Heavy-duty grapple 2450 mm Heavy-duty grapple 96 in. |
| Bucket weight | 375 kg 826 lb |
| Lift capacity at 59 in. (1500 mm) | Measured at pivot (W) 2989 kg 6590 lb Measured at 800 mm ahead of pivot (X) 2821 kg 6219 lb |
| Dimensions | Maximum lift height (A) 4480 mm 176 in. At full height - bucket level(B) 4240 mm 167 in. At full height - bucket dumped (C) 3465 mm 136 in. |
| Overall length (I+F), ft (m) | 5.5 m 17.9 ft |
| Digging depth (H) | 96 mm 5 in. |
| Reach | At maximum height (D) 1346 mm 53 in. At ground level - bucket level (F) 2931 mm 115 in. |
| Bucket angle | Dump angle, degrees (E) 60 degree (angle) Rollback angle, degrees (G) 48 degree (angle) Dump angle, ground 117 degree (angle) |
| Cycle times | Loader raise, seconds 4.19 seconds Loader lower, seconds 2.89 seconds Bucket dump, seconds 1.81 seconds Bucket rollback, seconds 1.81 seconds |
