| Maximum lift height (A) | 4495 mm 177 in. |
| Lift capacity at full height | Measured at pivot (U) 2301 kg 5073 lb |
| Boom breakout force | Measured at pivot (Y) 3235 kgf 7132 lbf |
| Bucket rollback force capacity | At ground-level line (ZZ) 4492 kgf 9903 lbf |
| Clearance at full height - bucket dumped (C) | 3481 mm 137 in. |
| Dump angle, degrees (E) | 60 degree (angle) |
| Rollback angle, degrees (G) | 48 degree (angle) |
| Model | 6145R/M, 6155R/M |
| Front tire | 540/65R30 |
| Rear tire | 650/65R42 |
| Front axle configuration | MFWD |
| Wheelbase | 2765 mm 108.9 in. |
| Pump capacity | 114 L/min 30.1 gpm |
| Rated pressure | 200 bar 2900 psi |
| Base weight | 1674.3 kg |
| Leveling configuration | Mechanical Self Leveling (MSL) |
| Bucket used | Heavy-duty grapple 2450 mm Heavy-duty grapple 96 in. |
| Bucket weight | 375 kg 826 lb |
| Lift capacity at 59 in. (1500 mm) | Measured at pivot (W) 2814 kg 6204 lb Measured at 800 mm ahead of pivot (X) 2645 kg 5831 lb |
| Dimensions | Maximum lift height (A) 4495 mm 177 in. At full height - bucket level(B) 4255 mm 168 in. At full height - bucket dumped (C) 3481 mm 137 in. |
| Overall length (I+F), ft (m) | 5.6 m 18.4 ft |
| Digging depth (H) | 81 mm 3 in. |
| Reach | At maximum height (D) 1038 mm 41 in. At ground level - bucket level (F) 2848 mm 112 in. |
| Bucket angle | Dump angle, degrees (E) 60 degree (angle) Rollback angle, degrees (G) 48 degree (angle) Dump angle, ground 118 degree (angle) |
| Cycle times | Loader raise, seconds 3.91 seconds Loader lower, seconds 2.7 seconds Bucket dump, seconds 1.81 seconds Bucket rollback, seconds 1.81 seconds |
