| Maximum lift height | 3343 mm 132 in. |
| Lift capacity at full height | Measured at pivot 1182 kg 2606 lb |
| Boom breakout force | Measured at pivot 2174 kgf 4793 lbf |
| Bucket rollback force capacity | At ground-level line 3058 kgf 6742 lbf |
| Clearance at full height - bucket dumped | 2516 mm 99.1 in. |
| Dump angle, degrees | -54 degree (angle) |
| Rollback angle, degrees | 43 degree (angle) |
| Model | 5085E, 5090E, 5100E FT4 |
| Front tire | 320/85 R24 BKT (12.4 R24) |
| Rear tire | 18.4 R30 |
| Wheelbase | 90 in. |
| Pump capacity | 11 gpm |
| Rated pressure | 2828 psi |
| Base weight | 826.9 kg |
| Leveling configuration | Mechanical Self Leveling (MSL) |
| Bucket used | General Purpose 1850 mm 73 in. |
| Bucket weight | 178 kg 392 lb |
| Lift capacity at 59 in. (1500 mm) | Measured at pivot 1611 kg 3552 lb Measured at 800 mm ahead of pivot 1584 kg 3492 lb |
| Dimensions | Maximum lift height 3343 mm 132 in. At full height - bucket level 3148 mm 124 in. At full height - bucket dumped 2516 mm 99.1 in. |
| Overall length | 4.5 m 14.7 ft |
| Digging depth | 93 mm 3.7 in. |
| Reach | At maximum height 839 mm 33 in. At ground level - bucket level 2172 mm 85.5 in. |
| Bucket angle | Dump angle, degrees -54 degree (angle) Rollback angle, degrees 43 degree (angle) Dump angle, ground -109 degree (angle) |
| Cycle times | Loader raise, seconds 3.3 seconds Loader lower, seconds 2.2 seconds Bucket dump, seconds 2.6 seconds Bucket rollback, seconds 2.6 seconds |
Inventory moves fast. Call your nearest store to confirm this unit is still here and get the current price.
Yes. Send us the make, model, year and hours of your machine and we will apply the equity.
Often yes, through John Deere Financial and outside lenders depending on the machine. Subject to approved credit and to change.
Yes. We move equipment between all 17 of our Indiana and Ohio dealerships.
Tell us what you want to know about the John Deere 520M.
