| Code | Bundle Description |
| 3592 | BXX10936 Two Function hoses and parts Note: Connection of loader hoses directly to tractor mid-valve Note: To be used with #4995 |
| 3593 | BXX10936 BXX10937 Three Function hoses and parts Note: Connection of loader hoses directly to tractor mid-valve Note: To be used with #4995 |
| Maximum lift height | 3150 mm 124 in. |
| Lift capacity at full height | Measured at pivot 1463 kg 3225 lb |
| Boom breakout force | Measured at pivot 1975 kg 4354 lb |
| Bucket rollback force capacity | At ground-level line 3369 kg 7427 lb |
| Clearance at full height - bucket dumped | 2187 mm 86 in. |
| Dump angle, degrees | 57 degree (angle) |
| Rollback angle, degrees | 42 degree (angle) |
| Model | 5E 3-Cyl FT4 (5045E, 5050E, 5055E, 5060E, 5065E, 5067E, 5075E) |
| Front tire | 9.5 - 24 |
| Wheelbase | 80.7 in (205 cm) |
| Pump capacity | 11.4 gpm (43.2 lpm) |
| Rated pressure | 2828 psi |
| Leveling configuration | Non-Self Leveling (NSL) |
| Bucket used | General Purpose 1850 mm 73 in. |
| Bucket weight | 220 kg 458 lb |
| Lift capacity at 59 in. (1500 mm) | Measured at pivot 1715 kg 3780 lb Measured at 800 mm ahead of pivot 1208 kg 2663 lb |
| Dimensions | Maximum lift height 3150 mm 124 in. At full height - bucket level 2964 mm 116 in. At full height - bucket dumped 2187 mm 86 in. |
| Overall length | 4207 mm 165 in. |
| Digging depth | 122 mm 4.8 in. |
| Reach | At maximum height 486 mm 19 in. At ground level - bucket level 2157 mm 85 in. |
| Bucket angle | Dump angle, degrees 57 degree (angle) Rollback angle, degrees 44 degree (angle) Dump angle, ground 149 degree (angle) |
| Cycle times | Loader raise, seconds 2.8 seconds Loader lower, seconds 2 seconds Bucket dump, seconds 4.2 seconds Bucket rollback, seconds 3 seconds |
