| Maximum lift height (A) | 2850 mm 112.1 in. |
| Lift capacity at full height | Measured at pivot (U) 1087 kg 2396 lb Measured at 500 mm ahead of pivot (V) 800 kg 1764 lb |
| Boom breakout force | Measured at pivot (Y) 1743.7 kg 3853 lb Measured at 500 mm ahead of pivot (Z) 1315.4 kgf 2902 lbf |
| Bucket rollback force capacity | At ground-level line (ZZ) 3485 lb 1580 kg |
| Clearance at full height - bucket dumped (C) | 2298 mm 90.4 in. |
| Dump angle, degrees (E) | 42 degree (angle) |
| Rollback angle, degrees (G) | 28.6 degree (angle) |
| Model | 4044M, 4049M, 4052M, 4066M and OOS: 4044R, 4049R, 4052R, 4066R |
| Front tire | 25x10-16.5 4PR R4 |
| Rear tire | 16.9-24 4PR |
| Wheelbase | 1850 mm 73 in. |
| Pump capacity | 10.2 gpm |
| Rated pressure | 2500 psi |
| Base weight | 150.99 kg |
| Bucket used | Materials |
| Bucket weight | 108 kg 238 lb |
| Lift capacity at 59 in. (1500 mm) | Measured at pivot (W) 1307 kg 2881 lb Measured at 500 mm ahead of pivot (X) 1043 kg 2299 lb |
| Dimensions | Maximum lift height (A) 2850 mm 112.1 in. At full height - bucket level(B) 2646 mm 104.1 in. At full height - bucket dumped (C) 2298 mm 90.4 in. |
| Overall length (I+F), ft (m) | 3.522 m 11.5 ft |
| Overall height in carry position (J) | 1.5 m 4.94 ft |
| Digging depth (H) | -146 mm 5.7 in. |
| Reach | At maximum height (D) 705 mm 27.7 in. At ground level - bucket level (F) 1672 mm 65.8 in. |
| Bucket angle | Dump angle, degrees (E) 42 degree (angle) Rollback angle, degrees (G) 28.6 degree (angle) Dump angle, ground 128.2 degree (angle) |
| Cycle times | Loader raise, seconds 4.26 seconds Loader lower, seconds 3.13 seconds Bucket dump, seconds 3.14 seconds Bucket rollback, seconds 2.42 seconds |
