| Maximum lift height | 2284 mm 90 in. |
| Lift capacity at full height | Measured at pivot 617 kg 1360 lb Measured at 500 mm ahead of pivot 453 kg 999 lb |
| Boom breakout force | Measured at pivot 1295 kg 2855 lb Measured at 500 mm ahead of pivot 922 kg 2032 lb |
| Bucket rollback force capacity | At ground-level line 1188 kg 2619 lb |
| Clearance at full height - bucket dumped | 1743 mm 69 in. |
| Dump angle, degrees | 43 degree (angle) |
| Rollback angle, degrees | 25 degree (angle) |
| Model | 3120/3320/3520/3720/3033R/3039R/3046R |
| Front tire | 7.00-14 6PR R1 |
| Rear tire | 11.2-24 6PR R1 |
| Wheelbase | 1727 mm 68 in. |
| Pump capacity | 8.6 gpm |
| Rated pressure | 2500 psi |
| Base weight | 257.21 kg |
| Bucket weight | 93.8 kg 207 lb |
| Lift capacity at 59 in. (1500 mm) | Measured at pivot 771 kg 1700 lb Measured at 500 mm ahead of pivot 595 kg 1312 lb |
| Dimensions | Maximum lift height 2284 mm 90 in. At full height - bucket level 2123 mm 83.5 in. At full height - bucket dumped 1743 mm 69 in. |
| Overall length | 3.122 m 10.24 ft |
| Digging depth | 76 mm 2.9 in. |
| Reach | At maximum height 773 mm 30.4 in. At ground level - bucket level 1381 mm 54.4 in. |
| Bucket angle | Dump angle, degrees 43 degree (angle) Rollback angle, degrees 25 degree (angle) |
| Cycle times | Loader raise, seconds 2.76 seconds Loader lower, seconds 1.69 seconds Bucket dump, seconds 2.91 seconds Bucket rollback, seconds 1.72 seconds |
Inventory moves fast. Call your nearest store to confirm this unit is still here and get the current price.
Yes. Send us the make, model, year and hours of your machine and we will apply the equity.
Often yes, through John Deere Financial and outside lenders depending on the machine. Subject to approved credit and to change.
Yes. We move equipment between all 17 of our Indiana and Ohio dealerships.
Tell us what you want to know about the John Deere 300R.
