| Maximum lift height (A) | 2140 mm 84 in. |
| Lift capacity at full height | Measured at pivot (U) 539 kg 1186 lb Measured at 500 mm ahead of pivot (V) 384 kg 845 lb |
| Boom breakout force | Measured at pivot (Y) 760 kg 1704 lb Measured at 500 mm ahead of pivot (Z) 537 kg 1204 lb |
| Bucket rollback force capacity | At ground-level line (ZZ) 634 kg 1422 lb |
| Clearance at full height - bucket dumped (C) | 1596 mm 63 in. |
| Dump angle, degrees (E) | 43.8 degree (angle) |
| Rollback angle, degrees (G) | 31.4 degree (angle) |
| Model | 3025E, 3032E, 3038E |
| Front tire | 25x8.50-14 4PR R4 |
| Rear tire | 15.00-19.5 4PR |
| Wheelbase | 1595 mm 62.8 in. |
| Pump capacity | 5.3 gpm |
| Rated pressure | 2495 psi |
| Base weight | 306.4 kg |
| Bucket used | Materials - 1550 mm |
| Bucket weight | 93 kg 205 lb |
| Lift capacity at 59 in. (1500 mm) | Measured at pivot (W) 588 kg 1294 lb Measured at 500 mm ahead of pivot (X) 444 kg 977 lb |
| Dimensions | Maximum lift height (A) 2140 mm 84 in. At full height - bucket level(B) 1979 mm 78 in. At full height - bucket dumped (C) 1596 mm 63 in. |
| Overall length (I+F), ft (m) | 2.9 m 9.5 ft |
| Overall height in carry position (J) | 161 mm 6 in. |
| Digging depth (H) | 131 mm 5 in. |
| Reach | At maximum height (D) 603 mm 24 in. At ground level - bucket level (F) 1369 mm 54 in. |
| Bucket angle | Dump angle, degrees (E) 43.8 degree (angle) Rollback angle, degrees (G) 31.4 degree (angle) Dump angle, ground 122 degree (angle) |
| Cycle times | Loader raise, seconds 3.31 seconds Loader lower, seconds 2.75 seconds Bucket dump, seconds 1.75 seconds Bucket rollback, seconds 1.88 seconds |
Inventory moves fast. Call your nearest store to confirm this unit is still here and get the current price.
Yes. Send us the make, model, year and hours of your machine and we will apply the equity.
Often yes, through John Deere Financial and outside lenders depending on the machine. Subject to approved credit and to change.
Yes. We move equipment between all 17 of our Indiana and Ohio dealerships.
Tell us what you want to know about the John Deere 300E.
