| Maximum lift height | 1809 mm 71.2 in. |
| Lift capacity at full height | Measured at pivot 375 kg 825 lb Measured at 500 mm ahead of pivot 259 kg 570 lb |
| Boom breakout force | Measured at pivot 806 kg 1808 lb Measured at 500 mm ahead of pivot 552 kg 1238 lb |
| Bucket rollback force capacity | At ground-level line 707 kg 1559 lb |
| Clearance at full height - bucket dumped | 1371 mm 54 in. |
| Dump angle, degrees | -40.1 degree (angle) |
| Rollback angle, degrees | 31.2 degree (angle) |
| Model | 1023E/1026R Tractor |
| Front tire | 18x8.5-10 4PR R4 |
| Rear tire | 26x12.00-12 4PR R4 |
| Wheelbase | 1450 mm 57 in. |
| Pump capacity | 3.5 gpm |
| Rated pressure | 1987 psi |
| Base weight | 220.5 kg |
| Bucket used | Pin on Materials 1250 mm 49 in. |
| Bucket weight | 53 kg 117 lb |
| Lift capacity at 59 in. (1500 mm) | Measured at pivot 429 kg 944 lb Measured at 500 mm ahead of pivot 309 kg 680 lb |
| Dimensions | Maximum lift height 1809 mm 71.2 in. At full height - bucket level 1653 mm 65.1 in. At full height - bucket dumped 1371 mm 54 in. |
| Overall length | 2.6 m 8.6 ft |
| Digging depth | -101 mm -4.0 in. |
| Reach | At maximum height 571 mm 22.5 in. At ground level - bucket level 1176 mm 46.3 in. |
| Bucket angle | Dump angle, degrees -40.1 degree (angle) Rollback angle, degrees 31.2 degree (angle) Dump angle, ground -114.0 degree (angle) |
| Cycle times | Loader raise, seconds 4.0 seconds Loader lower, seconds 2.5 seconds Bucket dump, seconds 5.7 (without regen)/2.2 (with regen) seconds Bucket rollback, seconds 3.5 seconds |
