| Tractor PTO hp range | Minimum 89 kg 120 hp |
| Tractor RPM | 1,000 rpm |
| Number of knives | 248 side slicer (124 pairs) |
| Knife dimensions | 7.87 x 63.5 mm 0.31 x 2.5 in. |
| Knife mounting system | Bracket and D-ring |
| Type | Alloy steel, hardened with vanadium carbide and reversible |
| Knives overlap | 27.18 mm 1.07 in. |
| Tip speed | 224 km/h 139 mph |
| Rotor speed | 2,000 rpm |
| Rotor diameter | Square rotor 17.8 x 17.8 cm 7 x 7 in. |
| Rotor bearing | Double-row, barrel-type, triple-sealed, 2-year warranty |
| Bearing size | 42.86 mm 1.69 in. |
| Belts | Kevlar, 3/5V heavy-duty |
| PTO drivelines | 44.5 and 35.1 mm 1.75 and 1.38 in. |
| Hitch | Drawn or Integral (Cat. 3 or 3N Quik-Coupler required) |
| Safety deflector | Rubber deflector |
| Gauge wheels | 4 (Drawn), 2 (Integral); infinitely adjustable |
| Warning lights | Integral (standard), drawn (optional) |
| Cutting width | 6.1 m 20 ft |
| Cutting height | 7.6-25.4 cm 3-10 in. |
| Transport width | Endwise; drawn 2.39 m 7.83 ft Integral 6.48 m 21.25 ft |
| Transport length | Endwise; drawn 7.34 m 24.08 ft Integral 2.39 m 7.83 ft |
| Weight | 2,268 kg 5,000 lb |
| Easy transport | Available |
| Constant velocity joint driveline | Available |
| Skid shoes | Available |
