| Capacity, Cutting (in.) | 1.18 in. |
| Height, Cutting (in.) | 0.98 /1.96 /2.99 in. |
| Height, Overall (in.) | 39 in. |
| Length, Overall (in.) | 79.5 in. |
| Width, Cutting (in) | 63 in. |
| Width, Overall (in.) | 77.16 in. |
| Weight (lbs.) | 936 lb |
| Tractor HP Required (min. - max.) | 45 - 75 hp |
| Tractor Weight MINIMUM (lbs.) | 3700 lb |
| COG (in) | 45.6 in. |
| Hitch Type | 3-point |
| iMatch Compatible | No |
| Hitch Category | 1 |
| Hitch Position | Offset |
| Offset Range | Left of Center (12) Fully Extended (94.5) |
| Hydraulic Offset | Standard |
| Blade Type | Hammers (std); Y-Blade (service) |
| Number of Hammers | 22 |
| Type of Blades/ Hammers | 18/20 |
| Blade Tip Speed (ft/min) | 8937 ft |
| Rotor Diameter (in.) | 5 in. |
| Rotor Speed (rpm) | 2278 rpm |
| Rotor Thickness (mm.) | 8 mm |
| Rotor Work Diameter (in.) | 15 in. |
| Rotor Bearing Type | SPHERICAL ROLLER 22207 |
| Gear Box Speed (rpm) | 540 rpm |
| Drive Belts | 3 - SPB Lp=1320 |
| Gauge Roller Diameter (in.) | 5.5 in. |
| Hydraulic Quick Coupler Size (in.) | 1/2 in. |
| Frame Thickness (mm.) | 3 mm |
| Side Frame Thickness (mm.) | 5 mm |
| Roller Bearing Diameter (in) | 2.835 in. |
| Rear Roller Bearing Type | YAR 207-2FW/VA201 |
| Belt adjustment | Screw adjustment |
| Primary Pulley Diameter (mm.) | 225 mm |
| Secondary Pulley Diameter (mm.) | 160 mm |
| Hood Height (in.) | 18.89 in. |
| Side Case Height (in.) | 24.01 in. |
| PTO Yoke Height (in.) | 23.62 in. |
Inventory moves fast. Call your nearest store to confirm this unit is still here and get the current price.
Yes. Send us the make, model, year and hours of your machine and we will apply the equity.
Often yes, through John Deere Financial and outside lenders depending on the machine. Subject to approved credit and to change.
Yes. We move equipment between all 17 of our Indiana and Ohio dealerships.
Tell us what you want to know about the John Deere FL11S Series.
