| Capacity, Cutting (in.) | 1.5 |
| Height, Cutting (in.) | 0.98 /1.96 /2.99 |
| Height, Overall (in.) | 36.5 |
| Length, Overall (in.) | 44.3 |
| Width, Cutting (in) | 63 |
| Width, Overall (in.) | 68.88 |
| Weight (lbs.) | 718 lbs. |
| Tractor HP Required (min. - max.) | 30 - 55 hp |
| Tractor Weight MINIMUM (lbs.) | 2600 lbs. |
| COG (in) | 25 |
| Hitch Type | 3-point |
| iMatch Compatible | No |
| Hitch Category | 1 |
| Hitch Position | Centered |
| Offset Range | Left of Center (11-33) Right of Center (30-46) |
| Hydraulic Offset | Option |
| Blade Type | Hammers (std); Y-Blade (service) |
| Number of Hammers | 22 |
| Type of Blades/ Hammers | 18/20 |
| Blade Tip Speed (ft/min) | 8937 |
| Rotor Diameter (in.) | 5 |
| Rotor Speed (rpm) | 2278 rpm |
| Rotor Thickness (mm.) | 8 mm |
| Rotor Work Diameter (in.) | 15 |
| Rotor Bearing Type | SPHERICAL ROLLER 22207 |
| Gear Box Speed (rpm) | 540 rpm |
| Drive Belts | 3 - SPB Lp=1320 |
| Gauge Roller Diameter (in.) | 5.5 |
| Hydraulic Quick Coupler Size (in.) | 1/2 |
| Frame Thickness (mm.) | 3 mm |
| Side Frame Thickness (mm.) | 5 mm |
| Roller Bearing Diameter (in) | 2.835 |
| Rear Roller Bearing Type | YAR 207-2FW/VA201 |
| Belt adjustment | Screw adjustment |
| Primary Pulley Diameter (mm.) | 225 mm |
| Secondary Pulley Diameter (mm.) | 160 mm |
| Hood Height (in.) | 18.89 |
| Side Case Height (in.) | 24.01 |
| PTO Yoke Height (in.) | 18.18 |
