| Engine description | John Deere PowerTech™ 4045 EWL |
| Engine displacement | 4 cylinders: 4.5 L 276 cu in. |
| Rated engine power | At 2200 rpm: 77.4 kW 105 hp |
| Maximum engine power | 80.6 kW 108.0 hp |
| Rated PTO power (hp SAE) | At 2100 rpm: 66.2 kW 90 hp |
| Transmission type | PowrReverser™ 16F/16R with creeper |
| Hydraulic pump rated output | 94 L/min 24.7 gpm |
| Rear hitch category (SAE designation) | Category 2; convertible to 1 |
| Description | John Deere PowerTech™ 4045 EWL |
| Engine type | 4045HLV82 |
| Engine family | NJDXL04.5317 |
| Rated speed | 2200 rpm |
| Aspiration | Turbocharged/Air-to-Air Aftercooled |
| Cylinders liners | Wet sleeved |
| Emission level | Final Tier 4 |
| After treatment type | DOC/SCR |
| Displacement | 4 cylinders: 4.5 L 276 cu in. |
| Rated power | At 2200 rpm: 77.4 kW 105 hp |
| Power boost | At 1900 rpm: 4 percent |
| Engine peak torque | At 1600 rpm: 437 Nm 322 lb-ft |
| PTO torque rise | At 1600 rpm: 30 percent |
| Type | PowrReverser™ 16F/16R with creeper |
| Reverser | Left hand, electrohydraulic |
| Clutch; wet/dry | Wet |
| Creeper | PowrReverser™ 16F/16R with creeper |
| Pump rated output | 94 L/min 24.7 gpm |
| Available flow at a single rear SCV | 70 L/min 18.4 gpm |
| Number of rear selective control valves (SCVs) | Standard: Two Optional: Three |
| Number of mid selective control valves (SCVs) | Standard: Two Optional: Up to Three |
| Joystick SCV control | Mechanical |
| Hitch draft control load sense type | Mechanical or electrohydraulic |
| Remote control valves available | Standard: 2 Optional: 3 |
| Hitch category (SAE designation) | Category 2; convertible to 1 |
| Maximum lift capacity behind lift points | Standard: 2336 kg 5150 lb Optional: 2699 kg 5950 lb |
| Sensing type | Lower Link |
| Rear axle differential lock | Electrohydraulic |
| Drawbar category | Category 2 |
| Maximum vertical load | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb |
| Engine rpm (at rated PTO speeds) | 540 at 2100 rpm 540E at 1645 rpm 1000 at 2100 rpm |
| PTO actuation | Electrohydraulic |
| Final drive type | Inboard planetary |
| Differential controls | Electrohydraulic |
| Brakes, type and control | Hydraulic wet disc |
| Rear | MFWD: 230/95R48 R1W Radial |
| Wheel tread range | MFWD: 1340-1904 mm 52.8-75.0 in. |
| Turning radius with brakes | MFWD: 3.9 m 12.8 ft |
| Turning radius without brakes | MFWD: 4.7 m 15.4 ft |
| Alternator size | OOS: 90 amp Cab: 120 amp |
