| Engine description | John Deere PowerTech™ 4045 PWS |
| Engine displacement | 4 cylinders: 4.5 L 276 cu in. |
| Rated engine power | At 2400 rpm: 77.4 kW 105 hp |
| Maximum engine power | 79.2 kW 106.2 hp |
| Rated PTO power (hp SAE) | At 2400 rpm: 67.1 kW (90 hp) |
| Transmission type | Standard: PowrReverser™ 12F/12R Optional: PowrReverser™ 24F/12R |
| Hydraulic pump rated output | 94 L/min 24.9 gpm |
| Rear hitch category (SAE designation) | Category 2N; convertible to 1 |
| Description | John Deere PowerTech™ 4045 PWS |
| Engine type | 4045HLV83 |
| Engine family | _JDXL06.8324 |
| Rated speed | 2400 rpm |
| Aspiration | Turbocharged |
| Cylinders liners | Wet sleeved |
| Emission level | Final Tier 4 / Stage 5 |
| After treatment type | DOC/DPF/SCR |
| Displacement | 4 cylinders: 4.5 L 276 cu in. |
| Rated power | At 2400 rpm: 77.4 kW 105 hp |
| Power boost | 2 percent |
| Engine peak torque | At 1700 rpm: 397 Nm 292 lb-ft |
| PTO torque rise | 28.9 percent |
| Type | Standard: PowrReverser™ 12F/12R Optional: PowrReverser™ 24F/12R |
| Reverser | Yes |
| Clutch; wet/dry | Wet |
| Creeper | Optional |
| Pump rated output | 94 L/min 24.9 gpm |
| Available flow at a single rear SCV | 68.8 L/min 18.2 gpm |
| Number of rear selective control valves (SCVs) | Standard: Two Optional: Three |
| Number of mid selective control valves (SCVs) | Standard: Zero Optional: Up to Two |
| Joystick SCV control | Mechanical |
| Hitch draft control load sense type | Electrohydraulic |
| Remote control valves available | Standard: Two |
| Hitch category (SAE designation) | Category 2N; convertible to 1 |
| Maximum lift capacity behind lift points | 1390 kg 3604 lb |
| Sensing type | Top link |
| Maximum vertical load | Field use (fully extended): 650 kg 1433 lb |
| Engine rpm (at rated PTO speeds) | 540 at 2400 rpm 540E at 1716 rpm |
| PTO actuation | Electrohydraulic |
| Final drive type | Planetary |
| Differential controls | Mechanical (pedal) |
| Brakes, type and control | Hydraulic wet disc |
| Rear | 14.9-24 In. 8PR R1 Bias (With 9.5-16 BIAS Front) |
| Turning radius with brakes | 3.56 m 11.67 ft |
| Turning radius without brakes | 5.18 m 16.99 ft |
| Alternator size | Cab: 110 amp |
| Battery options | 12 V |
| Working lights | Standard: LED |
| Type of bulb in headlight (Halogen, Zenon, LED) | Standard: LED |
