New
Tillage Attachments
John Deere TM10L Series
Request price
Available through TRULAND Equipment
- Category
- Tillage Attachments
- Type
- Tillage Attachments
- Condition
- New
| Working Width | 48 in. |
| Overall Width, in. (cm) | 50 (127) in. |
| Overall Height, in. (cm) | 34 (86.4) in. |
| Overall Length, in. (cm) | 52 (130.1) in. |
| Disk Spacing | 7.5 in. |
| Disk Thickness | 3 mm (0.118 In.) |
| Disk Diameter, in. (cm) | 16 (40.6) |
| Number of Disks | 12 |
| Front Gang Blade Type | Notched |
| Rear Gang Blade Type | Notched |
| Operating Weight | 437 lb |
| Shipping Weight | 452 lb |
| Weight per Disc (Approx.), lb (kg) | 36 (16.3) |
| Engine HP Range (kW) | 15-25 (11.2-18.6) |
| Category | Limited Category I |
| iMatch / Quick hitch | Yes |
| Type | Clevis with Pin |
| Height to Hitch Pins, in. (cm) | 14 (35.6) |
| Diameter, in. | 1 |
| Front Gang Angles | 0,7,14,21 Degrees |
| Rear Gang Angles | 0,5,12,19 Degrees |
| Adjustment | Tool-less |
| Gang / Frame Tubing | 2x3 rectangle with end caps |
| Bearing type | Self Aligning Sealed Ball Bearing in Pre-Riveted Flange |
