New
Corn Heads
John Deere CS770
Request price
Available through TRULAND Equipment
- Category
- Corn Heads
- Type
- Corn Heads
- Condition
- New
| Engine | Rated power 384 kW 515 hp Power boost 24.6 kW 33 hp John Deere JD14P 13.6 L 830 cu in. |
| Module shape | Round/cylindrical |
| Module dimensions | Diameter up to 244 cm 96 in. Width up to 239 cm 94 in. |
| Module weight | 1,995-2,449 kg 4,400-5,400 lb |
| Configurations | Number of rows Eight or twelve SH8R, SH12R, SH12F |
| On-board cleaner | Type Three drum Yes |
| Cooling system | Variable pitch reversible fan Yes Ground-level access to coolers Yes |
| Fuel system | Type Electronic unit direct injection Governor Electronic On-board diagnostics Yes |
| Hydrostatic system | Type Hydrostatic/mechanical drive Wet, multiple disc |
| Tires | Standard drive tire 520/85R42 (20.8R42) R1W Dual wheels Yes Dual tire size (standard) 520/85R42 (20.8R42) R1W Standard steering tire IF580/80R34 R1W |
| Rear wheel drive | Yes (full time) |
| Module Shape | Round/cylindrical |
| Module Dimensions | Diameter up to 244 cm 96 in. Width up to 239 cm 94 in. |
| Module Weight | 1,995.8-2,449.4 kg 4,400-5,400 lb |
| Unload on-the-go | Yes |
| Wrap system carrying capacity | 120 portions |
| Stripping units | Style Bat/brush stripping units Unit drive protection Slip clutch - one per unit |
| Row guidance | Manual RowSense™ system / AutoTrac™ RowSense system |
| Tank capacities | Fuel tank 1,022 L 270 gal. Water solution tank 257 L 68 gal. Diesel exhaust fluid tank 104.4 L 27.5 gal. |
| Hydraulic system | Pump type Pressure/ flow compensated Pressure 210 bar 3,050 psi Flow 223 L/min 59 gpm |
| Lengths | Overall length 11.1 m 36.5 ft Wheelbase 4.3 m 14.2 ft |
| Heights | Transport Position 4.8 m 15.7 ft Full Height Position 5.3 m 17.5 ft |
| Date collected | 2-Aug-2021 |
Inventory moves fast. Call your nearest store to confirm this unit is still here and get the current price.
Yes. Send us the make, model, year and hours of your machine and we will apply the equity.
Often yes, through John Deere Financial and outside lenders depending on the machine. Subject to approved credit and to change.
Yes. We move equipment between all 17 of our Indiana and Ohio dealerships.
Tell us what you want to know about the John Deere CS770.
