New
Corn Heads
John Deere CP770
Request price
Available through TRULAND Equipment
- Category
- Corn Heads
- Type
- Corn Heads
- Condition
- New
| Engine | Rated power 414 kW 555 hp Power Boost 25 kW 34 hp John Deere JD14P 13.6 L 830 cu in. |
| Module Shape | Round/cylindrical |
| Module Dimensions | Diameter up to 244 cm 96 in. Width up to 239 cm 94 in. |
| Module Weight | 2,222-2,676 kg 4,900-5,900 lb |
| Spacings | 76.2, 91.4, 96.5, 101.6 cm 30, 36, 38, 40 in. |
| Picking Units Style | In-line spindle-type picking units |
| Units Available | MP16 |
| Bars Front and Rear | 16 front drum, 12 rear drum |
| Cooling System | Variable pitch reversible fan Yes Rotary Screen Yes Ground Level Access to Coolers Yes |
| Fuel System | Type High-pressure common rail Governor Electronic On Board Diagnostics Yes |
| Hydrostatic System | Type Hydrostatic/mechanical drive Wet, multiple disc |
| Rear Wheel Drive | Yes (full time) |
| Unload on-the-go | Yes |
| Wrap system carrying capacity | 120 portions |
| Configurations | Number of Rows Six Spacings 76.2, 91.4, 96.5, 101.6 cm 30, 36, 38, 40 in. |
| Row Guidance | Manual RowSense™ / AutoTrac™ RowSense |
| Fuel Tank | 1,250 L 330 gal. |
| Moistener System | Quick Fill Yes 1,363 L 360 gal. |
| Lube | 257 L 68 gal. |
| Diesel Exhaust Fluid Tank | 104.4 L 27.5 gal. |
| Pump Type | Pressure 210 bar 3,050 psi Flow 223 L/min 59 gpm Pressure/ flow compensated |
| Lengths | Overall Length 10.2 m 33.4 ft Wheel Base 4.3 m 14.2 ft |
| Heights | Transport Position 4.4 m 14.5 ft Full Height Position 5.2 m 17.2 ft |
| Weights | 6-Row 31,257 kg 68,900 lb |
| Date collected | 2-Aug-2021 |
Inventory moves fast. Call your nearest store to confirm this unit is still here and get the current price.
Yes. Send us the make, model, year and hours of your machine and we will apply the equity.
Often yes, through John Deere Financial and outside lenders depending on the machine. Subject to approved credit and to change.
Yes. We move equipment between all 17 of our Indiana and Ohio dealerships.
Tell us what you want to know about the John Deere CP770.
