| Engine description | JD18 (John Deere 18L) |
| Engine displacement | 18 L 1098 cu in. |
| Rated engine power | ECE-R120: 566 kW 770 PS (hp ISO) 759 hp (SAE) |
| Maximum engine power | ECE-R120: 623 kW 847 PS (hp ISO) 835 hp (SAE) |
| Rated PTO power (hp SAE) | 249 kW 385 hp Rated value listed occurs when tractor is stationary |
| Transmission type | John Deere e21 21-speed PowerShift; 21F, 11R with Efficiency Manager: 40 km/h 25 mph |
| Hydraulic pump rated output | Single: 212 L/min 56 gpm Dual: 424 L/min 112 gpm Triple: 636 L/min 168 gpm |
| Base machine weight | 33,500 kg 74,000 lb |
| Description | JD18 (John Deere 18L) |
| Engine type | In-line six, six-cylinder |
| Rated speed | 1900 rpm |
| Aspiration | Dual turbochargers in series; Primary fixed displacement turbocharger and secondary wastegated turbocharger, air-to-air aftercooling, and cooled exhaust gas recirculation (EGR) |
| Cylinders liners | Wet-sleeve |
| Emission level | Final Tier 4 (FT4) / Stage V Compliant Diesel Engine |
| After treatment type | Exhaust Gas Recirculation (EGR) - No Diesel Exhaust Fluid (DEF) used |
| Displacement | 18 L 1098 cu in. |
| Rated power | ECE-R120: 566 kW 770 PS (hp ISO) 759 hp (SAE) |
| Intelligent Power Management (IPM) | 40 hp at rated engine RPM |
| Power boost | 10 percent |
| Engine peak torque | At 1400 rpm: 3928 Nm 2897 lb-ft |
| PTO torque rise | 38 percent at 1400 rpm |
| Type | John Deere e21 21-speed PowerShift; 21F, 11R with Efficiency Manager: 40 km/h 25 mph |
| Pump rated output | Single: 212 L/min 56 gpm Dual: 424 L/min 112 gpm Triple: 636 L/min 168 gpm |
| Available flow at a single rear SCV | 1.3-cm (1/2 in.) couplers: 140 L/min 35 gpm 1.9-cm (3/4-in.) couplers: 180 L/min 44 gpm |
| SCV control | Electronic |
| Drawbar category | Category 5 |
| Maximum vertical load | 8618 kg 19,000 lb |
| PTO actuation | Electrohydraulic |
| Final drive type | Outboard planetary with three planetary gears |
| Rear differential lock | Full-locking electrohydraulic |
| Front axle differential lock | Full-locking electrohydraulic |
| Turning radius with brakes | Turning radius calculated off rear axle centerline 679.5 cm 22.3 ft |
| Tread spacing | Only compatible with 762 mm (30 in.) tracks: 2235 mm 88 in. Optional: 3048 mm 120 in. |
| Drive type | Camso ® Ag 3500 or 6500 Tracks |
| Track width | Standard: 762 mm 30 in. Optional - only compatible with 3048 mm (120 in.) spacing: 914 mm 36 in. |
| Mid-rollers | Three |
| Alternator size | 330 amp |
| Battery options | 12 V |
| Working lights | Standard: 18 halogen Optional: 20 or 24 light-emitting diode (LED) |
| Type of bulb in headlight (Halogen, Zenon, LED) | Select Visibility: Halogen: 65 W Premium and Ultimate Visibility: LED |
| Total cold cranking amps | 5 x 950 CCA Total: 4750 CCA |
| Cab suspension | Standard |
| Instructional seat | Standard |
| Display | Standard: G5 Plus CommandCenterâ„¢: 32.5 cm 12.8 in. |
| Radio | Varies by comfort and convenience package |
| Inner cab volume | 3.37 m 3 119 cu ft |
| Cab glass area | 6.86 m 2 73.81 sq ft |
| Wheelbase | Distance from the center of the front drive sprocket to the center of the rear drive sprocket: 4620 mm 15.2 ft |
