| Engine Make | John Deere |
| Engine Model | JD9 |
| Engine Family | VJDXL09.0333 |
| Displacement (L) | 9 |
| Displacement (cu in.) | 549 |
| Rated Engine Power (hp) | 306 |
| Rated Engine Power (kw) | 228 |
| Rated Engine Power (PS) | 310 |
| Maximum Engine Power (hp) | 336 |
| Maximum Engine Power (kW) | 251 |
| Maximum Engine Power (PS) | 341 |
| Transmission Type | Standard: e23™ PowerShift™ 40K, 40 km/h 24.9 mph Optional: John Deere AutoPowr™ IVT™ 40K, 0.05-42 km/h 0.03-26 mph |
| Rear Hitch Category (SAE Designation) | Category 4N/3 at 610 mm (24 in.) behind hitch point: 9,072 kg 20,000 lb Optional: Category 4N/3 at 610 mm (24 in.) behind hitch point: 6,803 kg 15,000 lb |
| Pump Rated Output | 85-cc pump: 227.1 L/min 60 gpm |
| Base Machine Weight (lb) | 34,400 |
| Base Machine Weight (kg) | 15,600 |
| Wheel or Track Configuration | 2-Track |
| Emissions Certifications | Final Tier 4 |
| Aspiration | Single, variable geometry turbo; air-to-air aftercooling and cooled exhaust gas recirculation |
| Number of Cylinders | Six |
| Cylinder Liners | Wet-sleeve |
| Aftertreatment Type | Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF)/selective catalytic reduction (SCR) |
| Rated Engine Speed (rpm) | 2,100 |
| Rated Engine Power (kW) | 228 |
| Engine Torque at Rated Speed (lb-ft) | 1,070 |
| Engine Torque at Rated Speed (Nm) | 1,452 |
| Maximum Engine Torque | At 1,600 rpm: 1,452 Nm 1,070 lb-ft |
| Power Bulge (%) | 10 |
| Fuel Type | Diesel |
| Alternative Fuel Type | B30 Diesel Compatible |
| Torque Rise (%) | 40 |
| Maximum Speed Forward | Standard: 40 km/h 25 mph Optional: 42 km/h 26 mph |
| Minimum Speed Forward | 0.05 km/h 0.03 mph |
| PTO Category | 45 mm 1.75 in. 20-spline, 1,000 rpm |
| Rated PTO Power (hp) | 257 |
| Rated PTO Power (kW) | 191 |
| Rated PTO Power (PS) | 261 |
| Engine rpm at Rated PTO Speeds (540/1.000) | 1,000 PTO rpm 2,000 rpm |
| Engagement Method | Electrohydraulic with adjustable modulation |
| Number of Splines | 20 |
| Maximum Lift Capacity at 610-mm Behind Hitch Point | Standard (at 610-mm [24-in.] behind hitch point): 12,124 kg 26,729 lb |
| Sensing Type | Electrohydraulic |
| Drawbar Category | Category 4 with heavy-duty support Optional: Category 4 |
| Maximum Vertical Load | 4,990 kg 11,000 lb Optional: 2,245 kg 4,950 lb |
| Hydraulic System Type | Closed-center, pressure/flow compensated system with load sensing |
| Number of Rear Selective Control Valves (SCVs) | Standard: 1.3-cm (1/2-in.) ISO couplers: four Optional: 1.3-cm (1/2-in.) ISO couplers: five and six available |
| Available Flow at a Single Rear SCV | 1.3-cm (1/2-in.) couplers: 132 L/min 35 gpm |
| SCV Control | Electronic |
