| Engine Make | John Deere |
| Engine Model | John Deere PowerTech PVS |
| Engine Family | VJDXL06.8309 |
| Displacement (L) | 6.8 |
| Displacement (cu in.) | 418 |
| Rated Engine Power (hp) | 217 |
| Rated Engine Power (kw) | 162 |
| Rated Engine Power (PS) | 220 |
| Transmission Type | Standard: John Deere AutoPowr™/IVT™ 40 km/h Optional: John Deere AutoPowr™/IVT™ 50 km/h John Deere e19™ PowerShift 40 km/h & 50 km/h |
| Rear Hitch Category (SAE Designation) | Category 3/3N |
| Pump Rated Output | Standard: 155 L/min 41 gpm Optional: 210 L/min 55.5 gpm |
| Base Machine Weight (lb) | 19621 |
| Base Machine Weight (kg) | 8900 |
| Wheel or Track Configuration | Wheel |
| Drive Type | MFWD |
| Emissions Certifications | Final Tier 4 |
| Aspiration | Turbocharged, variable geometry turbocharger with air-to-air aftercooling and cooled exhaust gas recirculation |
| Number of Cylinders | Six |
| Cylinder Liners | Wet-sleeve |
| Aftertreatment Type | Cooled exhaust gas recirculation (EGR) Diesel Particle Filter (DPF) with Diesel Oxidation Catalyst (DOC) and Selective Catalytic Reduction (SCR) using DEF |
| Intelligent Power Management (IPM) | 40 |
| Rated Engine Speed (rpm) | 2,100 |
| Rated Engine Power (kW) | 162 |
| Rated Engine Power with IPM (hp) | 255 |
| Rated Engine Power with IPM (kw) | 190 |
| Rated Engine Power with IPM (PS) | 259 |
| Maximum Engine Speed (rpm) | 1,900 |
| Maximum Engine Power (hp) | 239 |
| Maximum Engine Power (kW) | 178 |
| Maximum Engine Power (PS) | 242 |
| Maximum Engine Power with IPM (hp) | 255 |
| Maximum Engine Power with IPM (kW) | 190 |
| Maximum Engine Power with IPM (PS) | 259 |
| Maximum Engine Torque | 1,025 Nm 756 lb-ft |
| Constant Power Range | 1,500 - 2,100 rpm |
| Power Bulge (%) | 10 |
| Bore and Stroke (in.) | 4.2 x 5.0 |
| Bore and Stroke (mm) | 106.5 x 127 |
| Compression Ratio | 16.7:1 |
| Lubrication | Pressure lubrication |
| Cooling System Type | Liquid |
| Fuel Type | Ultra-low sulfur diesel |
| Air Cleaner Type | PowerCore ® G2 Air Filter with pre-cleaning |
| Torque Rise (%) | 40 |
| Maximum Speed Forward | 50 km/h 31 mph |
| Minimum Speed Forward | 0.03 km/h 0.02 mph |
| Reverser | Left-hand electrical reverser |
| Cruise Control | Yes |
Inventory moves fast. Call your nearest store to confirm this unit is still here and get the current price.
Yes. Send us the make, model, year and hours of your machine and we will apply the equity.
Often yes, through John Deere Financial and outside lenders depending on the machine. Subject to approved credit and to change.
Yes. We move equipment between all 17 of our Indiana and Ohio dealerships.
Tell us what you want to know about the John Deere 6R 220.
