| Engine Make | John Deere |
| Engine Model | JD9 |
| Engine Family | VJDXL09.0333 |
| Displacement (L) | 9 |
| Displacement (cu in.) | 549 |
| Rated Engine Power (hp) | 247 |
| Rated Engine Power (kw) | 184 |
| Rated Engine Power (PS) | 250 |
| Maximum Engine Power (hp) | 271 |
| Maximum Engine Power (kW) | 202 |
| Maximum Engine Power (PS) | 275 |
| Rear Hitch Category (SAE Designation) | Category 3/3N Optional: Category 4N/3 |
| Pump Rated Output | Standard: 85-cc pump: 227.1 L/min 60 gpm Optional: 85-cc plus 35-cc dual pump: 318 L/min 84 gpm |
| Base Machine Weight (lb) | 25,800 |
| Base Machine Weight (kg) | 11,702 |
| Wheel or Track Configuration | Wheel |
| Drive Type | MFWD |
| Emissions Certifications | Final Tier 4 |
| Aspiration | Single, variable geometry turbo; air-to-air aftercooling and cooled exhaust gas recirculation |
| Number of Cylinders | Six |
| Cylinder Liners | Wet-sleeve |
| Aftertreatment Type | Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF)/selective catalytic reduction (SCR) |
| Rated Engine Speed (rpm) | 2,100 |
| Rated Engine Power (kW) | 184 |
| Engine Torque at Rated Speed (lb-ft) | 863 |
| Engine Torque at Rated Speed (Nm) | 1,171 |
| Maximum Engine Torque | At 1,600 rpm: 1,171 Nm 863 lb-ft |
| Power Bulge (%) | 10 |
| Fuel Type | Diesel |
| Alternative Fuel Type | B30 Diesel Compatible |
| Torque Rise (%) | 40 |
| Maximum Speed Forward | 50 km/h 31 mph |
| Minimum Speed Forward | 0.05 km/h 0.03 mph |
| PTO Category | Standard: 45 mm 1.75 in. 20-spline, 1,000 rpm Optional: 45 mm (1.75 in.), 20-spline, 1,000 rpm capable of 35 mm 1.375 in. 540/1000 rpm 45 mm 20-spline, 1,000 rpm/1,000E rpm |
| Rated PTO Power (hp) | 200 |
| Rated PTO Power (kW) | 149 |
| Rated PTO Power (PS) | 203 |
| Economy PTO Speeds | 1,000E rpm |
| Engine rpm at Rated PTO Speeds (540/1.000) | 1,810 / 1,995 |
| Engine rpm at Rated PTO Speeds (540E/1000/1.000E) | -- / 1,995 / 1,590 |
| Engagement Method | Electrohydraulic with adjustable modulation |
| Number of Splines | 20 |
| PTO Speed | 1,000 rpm |
| Front PTO Rotation | 35 mm 1.375 in. 21 spline, 1,000 rpm 45 mm 1.75 in. 20 spline, 1,000 rpm (available through parts only) 6 spline, 1,000 rpm (available dependent on location) |
| Engine rpm (at Rated PTO Speeds) | 2,000 |
| Front Hitch Category | Category 3N |
| Maximum Lift Capacity at 610-mm Behind Hitch Point | 9,072 kg 20,000 lb |
| Sensing Type | Electrohydraulic |
