| Engine displacement | 9.0 L 549 cu in. |
| Rated engine power | ECE-R120: 257 kW 350 hp |
| Maximum engine power | ECE-R120: 283 kW 385 hp |
| Rated PTO power (hp SAE) | 193 kW 260 hp |
| Transmission type | Standard: John Deer Infinitely Variable transmission (IVT™): 0.05-42 km/h 0.03-26 mph Optional: John Deere IVT: 0.05-50 km/h 0.03- 31 mph |
| Hydraulic pump rated output | Standard: 63 cc: 162 L/min 43 gpm Optional: 85 cc: 222.3 L/min 59 gpm |
| Rear hitch category (SAE designation) | Standard: Category 3N/3 with Quik-Coupler Optional: Category 3/3N with hook ends Category 4N/3 with Quik-Coupler Category 4N/3 with hook ends |
| Base machine weight | VT, TLS, 480/80R50 tires: 11,000 kg 24,300 lb |
| Engine type | Diesel, in-line, 6-cylinder, wet-sleeve cylinder liners with four valves in head |
| Engine family | MJDXL09.0319 |
| Rated speed | 2100 rpm |
| Aspiration | Single turbocharger, variable geometry turbo |
| Emission level | Final Tier 4 |
| After treatment type | Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF) |
| Displacement | 9.0 L 549 cu in. |
| Rated power | ECE-R120: 257 kW 350 hp |
| Power boost | IPM: 18.6 kW 25 hp |
| Engine peak torque | At 1600 rpm: 1,580 Nm 1,165 lb-ft |
| PTO torque rise | 40 percent |
| Type | Standard: John Deere IVT: 0.05-42 km/h 0.03-26 mph Optional: John Deere IVT: 0.05-50 km/h 0.03- 31 mph |
| Pump rated output | Standard: 63 cc: 162 L/min 43 gpm Optional: 85 cc: 222.3 L/min 59 gpm |
| Available flow at a single rear SCV | 132 L/min 35 gpm |
| Available flow at front SCVs | 126 L/min 33 gpm |
| Number of rear selective control valves (SCVs) | Standard: Four SCVs Optional: Three to five ISO couplers: 12.7 mm 0.5 in. Five ISO couplers (SCV 1-5: 12.7-mm [1/2-in.] coupler) |
| Number of front selective control valves (SCVs) | One with front hitch |
| SCV control | Electronic |
| Hitch category (SAE designation) | Standard: Category 3N/3 with Quik-Coupler Optional: Category 3/3N with hook ends Category 4N/3 with Quik-Coupler Category 4N/3 with hook ends |
| Sensing type | Electrohydraulic |
| Drawbar category | Standard: Category 4 |
| Maximum vertical load | Standard: Category 4: 4,990 kg 11,000 lb |
| Engine rpm (at rated PTO speeds) | 540/1000 PTO rpm at 1950 engine rpm 540E/1000E PTO rpm at 1750 engine rpm |
| PTO actuation | Electric switch with adjustable modulation |
| Category | Category 3N, ground engaging |
| Electric power | Seven-pin connector |
| Standard lift capacity | 5,200 kg 11,464 lb |
| PTO speed | 1,000 PTO rpm at 1940 engine rpm |
| Final drive type | Inboard planetary three pinion |
| Rear differential lock | Full-locking electrohydraulic |
| Front axle differential lock | Full-locking electrohydraulic (actuated at same time as rear diff lock) |
| Rear | RCI Group 48/49 |
| Turning radius with brakes | 600/70R30 group 43 tires at 188.2-cm (74.1-in.) spacing, TLS: 6.7 m 22 ft 620/75R30 group 44 tires at 208.3-cm (82-in.) spacing, TLS: 8.7 m 28.5 ft |
| Alternator size | Standard: 210 amp Optional: 250 amp |
| Battery options | 12 V |
| Working lights | Standard: 18 halogen Available: 18 LED 22 LED |
| Type of bulb in headlight (Halogen, Zenon, LED) | Standard: 65-W halogen Available: LED |
| Total cold cranking amps | With two 925-CCA group 31 batteries: 1850 CCA |
| Seat | Degree of seat swivel, left hand Optional: 25 degree Degree of seat swivel, right hand 40 degree Standard: Air seat Optional: ActiveSeat™ II |
| Cab suspension | Optional: Adjustable cab suspension |
