| Engine description | John Deere PowerTech™ (B20 diesel compatible) 6.8L |
| Engine displacement | 6.8 L 415 cu in. |
| Rated engine power | ECE-R120: 184 kW 250 hp |
| Maximum engine power | ECE-R120: 202 kW 275 hp |
| Rated PTO power (hp SAE) | 152 kW 205 hp |
| Hydraulic pump rated output | Standard: 63 cc: 162 L/min 43 gpm Optional: 85 cc: 222.3 L/min 59 gpm |
| Rear hitch category (SAE designation) | Standard: Category 3/3N with Quik-Coupler Optional: Category 3/3N with hook ends Category 3N/3 with hook ends |
| Base machine weight | e23, TLS™, 18.4R46: 10,000 kg 22,000 lb |
| Description | John Deere PowerTech™ (B20 diesel compatible) 6.8L |
| Engine type | Diesel, in-line, 6-cylinder, wet-sleeve cylinder liners with four valves in head |
| Engine family | MJDXL06.8309 |
| Rated speed | 2100 rpm |
| Aspiration | Dual turbochargers, variable geometry turbo with fixed geometry turbo in series |
| Emission level | Final Tier 4 |
| After treatment type | Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF) |
| Displacement | 6.8 L 415 cu in. |
| Rated power | ECE-R120: 184 kW 250 hp |
| Power boost | IPM: 25 kW 30 hp |
| Engine peak torque | At 1600 rpm: 1171 Nm 864 lb-ft |
| PTO torque rise | 40 percent |
| Type | Closed-center, pressure/flow compensated system with load sensing |
| Pump rated output | Standard: 63 cc: 162 L/min 43 gpm Optional: 85 cc: 222.3 L/min 59 gpm |
| Available flow at a single rear SCV | 132 L/min 35 gpm |
| Available flow at front SCVs | 126 L/min 33 gpm |
| Number of rear selective control valves (SCVs) | Standard: Four SCVs Optional: Three to six ISO couplers: 12.7 mm 1/2 in. Five ISO couplers (SCV 1: 19-mm [3/4-in.] couplers, SCV 2-5: 12.7-mm [1/2-in.] coupler) |
| Number of front selective control valves (SCVs) | One with front hitch |
| SCV control | Electronic |
| Hitch category (SAE designation) | Standard: Category 3/3N with Quik-Coupler Optional: Category 3/3N with hook ends Category 3N/3 with hook ends |
| Maximum lift capacity behind lift points | Standard (Category 3): 6894 kg 15,200 lb Optional (Category 3N): 7847 kg 17,300 lb Standard (Category 3 with hook ends): 6984 kg Optional (Category 3 with hook ends): 7847 kg |
| Sensing type | Electrohydraulic |
| Drawbar category | Standard: Category 3 Optional: Category 3 with heavy-duty support Category 4 |
| Maximum vertical load | Standard: Category 3: 1837 kg 4050 lb Optional: Category 3 with heavy-duty support: 4536 kg 10,000 lb |
| Engine rpm (at rated PTO speeds) | 540/1000 PTO rpm at 1950 engine rpm 540E/1000E PTO rpm at 1750 engine rpm |
| PTO actuation | Electric switch with adjustable modulation |
| Category | Category 3N, ground engaging |
| Electric power | Seven-pin connector |
| Standard lift capacity | 5,200 kg 11,464 lb |
| PTO speed | 1,000 PTO rpm at 1940 engine rpm |
| Final drive type | Inboard planetary three pinion |
| Rear differential lock | Full-locking electrohydraulic |
| Front axle differential lock | 1300 Series MFWD: Limited slip TLS: Limited slip TLS with front brakes: Full-locking electrohydraulic (actuated at same time as rear diff lock) |
| Rear | RCI Group 47/48/49 |
| Alternator size | Standard: 210 amp Optional: 250 amp |
| Battery options | 12 V |
| Working lights | Standard: 18 halogen Available: 18 LED or 22 LED |
| Type of bulb in headlight (Halogen, Zenon, LED) | Standard: 65-W halogen Available: LED |
| Total cold cranking amps | With two 925 CCA group 31 batteries: 1850 CCA |
| Seat | Degree of seat swivel, left hand Optional: 25 degree Degree of seat swivel, right hand 40 degree Standard: air suspension Optional: ActiveSeat™ II |
