| Visibility packages | Select Premium Ultimate |
| Lighting | 18 LED work lights 18 LED work lights 22 LED work lights and eight LED convenience lights** |
| Mirrors | Mechanical Electric, heated Electric, heated, and telescoping |
| Sunshades | Front Front, right-hand side, and rear Front, right-hand side, and rear |
| Wipers | Front and rear Front, right-hand side, and rear Front, right-hand side, and rear |
| Cameras | Camera ready Camera ready Integrated digital cameras |
| 1 | Accelerate Decelerate |
| 2 | Top set speed Zero speed |
| 3 | Decelerate Accelerate |
| 4 | Zero speed Accelerate |
| 5 | Activate set speed |
| 6 | Select direction |
| 7 | Inching speed |
| 8 | Inching speed |
| Large tractor equipment | Precision Technology JDLink |
| Engine description | John Deere PowerTech™ (B20 diesel compatible) 6.8L |
| Engine displacement | 6.8 L 415 cu in. |
| Rated engine power | ECE-R120: 154 kW 210 hp |
| Maximum engine power | ECE-R120: 170 kW 231 hp |
| Rated PTO power (hp SAE) | 126 kW 170 hp |
| Hydraulic pump rated output | Standard: 63 cc: 162 L/min 43 gpm Optional: 85 cc: 222.3 L/min 59 gpm |
| Rear hitch category (SAE designation) | Standard: Category 3/3N with Quik-Coupler Optional: Category 3/3N with hook ends |
| Base machine weight | e23, TLS™, 18.4R46: 10,000 kg 22,000 lb |
| Description | John Deere PowerTech™ (B20 diesel compatible) 6.8L |
| Engine type | Diesel, in-line, 6-cylinder, wet-sleeve cylinder liners with four valves in head |
| Engine family | MJDXL06.8309 |
| Rated speed | 2100 rpm |
| Aspiration | Single turbocharger, variable geometry turbo |
| Emission level | Final Tier 4 |
| After treatment type | Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF) |
| Displacement | 6.8 L 415 cu in. |
| Rated power | ECE-R120: 154 kW 210 hp |
| Power boost | IPM: 23 kW 30 hp |
| Engine peak torque | At 1600 rpm: 983 Nm 725 lb-ft |
| PTO torque rise | 40 percent |
| Type | Closed-center, pressure/flow compensated system with load sensing |
| Pump rated output | Standard: 63 cc: 162 L/min 43 gpm Optional: 85 cc: 222.3 L/min 59 gpm |
| Available flow at a single rear SCV | 132 L/min 35 gpm |
| Available flow at front SCVs | 126 L/min 33 gpm |
| Number of rear selective control valves (SCVs) | Standard: four SCVs Optional: Three to six ISO couplers: 12.7 mm 1/2 in. Five ISO couplers (SCV 1: 19-mm [3/4-in.] couplers, SCV 2-5: 12.7-mm [1/2-in.] coupler) |
| Number of front selective control valves (SCVs) | One with front hitch |
| SCV control | Electronic |
| Hitch category (SAE designation) | Standard: Category 3/3N with Quik-Coupler Optional: Category 3/3N with hook ends |
| Maximum lift capacity behind lift points | Standard (Category 3): 5443 kg 12,000 lb Optional (Category 3N): 6894 kg 15,200 lb Standard (Category 3 with hook ends): 5443 kg Optional (Category 3 with hook ends): 6894 kg 15,000 lb |
| Sensing type | Electrohydraulic |
| Drawbar category | Standard: Category 3 Optional: Category 3 with heavy-duty support Category 4 |
| Maximum vertical load | Standard: Category 3: 1,837 kg 4,050 lb Optional: Category 3 with heavy-duty support: 4,536 kg 10,000 lb |
| Engine rpm (at rated PTO speeds) | 540/1000 PTO rpm at 1950 engine rpm 540E/1000E PTO rpm at 1750 engine rpm |
