| Engine displacement | 6.8 L 415 cu in. |
| Rated PTO power (hp SAE) | 91 kW 122 hp |
| Hydraulic pump rated output | Standard: 45 cc pump: 114 L/min 30 gpm Optional: 60 cc pump: 155 L/min 41 gpm |
| Rear hitch category (SAE designation) | Category 3/3N: 4170 kg 9193 lb |
| Base machine weight | 7100 kg 15,653 lb |
| Engine type | Diesel, in-line, 6-cylinder, wet-sleeve cylinder liners with four valves in head |
| Engine family | NJDXL06.8324 |
| Rated speed | 2100 rpm |
| Aspiration | Turbocharged, variable geometry turbocharger with air-to-air aftercooling and cooled exhaust gas recirculation |
| Emission level | Final Tier 4 |
| After treatment type | DOC/DPF/SCR |
| Displacement | 6.8 L 415 cu in. |
| Intelligent Power Management (IPM) | Transport and/or mobile PTO applications Additional engine power (hp ISO) at 2100 rpm: 29.8 kW 40 hp |
| Power boost | 10 percent |
| Engine peak torque | At 1,600 rpm: 724 Nm 533 lb-ft |
| PTO torque rise | 40 percent |
| Reverser | Left-hand electrical reverser |
| Creeper | Available with AutoQuad |
| Type | Closed-center, pressure-and-flow compensated |
| Pump rated output | Standard: 45 cc pump: 114 L/min 30 gpm Optional: 60 cc pump: 155 L/min 41 gpm |
| Available flow at a single rear SCV | 100 L/min 26 gpm |
| Number of rear selective control valves (SCVs) | Standard: Three ISO couplers Optional: Three to five ISO couplers |
| Number of mid selective control valves (SCVs) | Up to three |
| Joystick SCV control | Available |
| SCV control | Standard: Mechanical Optional: Electronic |
| Remote control valves available | Available: Remote control switch |
| Hitch category (SAE designation) | Category 3/3N: 4170 kg 9193 lb |
| Maximum lift capacity behind lift points | 4200 kg 9259 lb |
| Sensing type | Electrohydraulic |
| Rear axle differential lock | Electrohydraulic |
| Drawbar category | Category 2 |
| Maximum vertical load | Category 2: 1400-2450 kg 3085-5400 lb Maximum vertical load dependent on drawbar position |
| Engine rpm (at rated PTO speeds) | 1967 engine rpm at 540 rpm PTO 1753 engine rpm at 540E rpm PTO 2000 engine rpm at 1000 rpm PTO |
| PTO actuation | Electrical modulation |
| Category | Category 3N |
| Electric power | Seven-pin electrical socket Optional: Three-pin and ISOBUS socket |
| Standard lift capacity | At hook ends: 3300 kg 7275 lb |
| Front power take-off (PTO) | 1000 rpm, clockwise rotation (from driving position) |
| PTO speed | Engine at PTO speed (1000): 1969 rpm |
| Final drive type | Inboard planetary three pinion |
| Differential controls | Full-locking electrohydraulic |
| Front axle differential lock | MFWD: Limited slip TLS: Limited slip TLS with brakes: Full-locking electrohydraulic |
| Rear | 480/80R42 R1/R1W Radial |
| Wheel tread range | MFWD: 1524-2235 mm 60-88 in. TLS: 1524-2235 mm 60-88 in. |
| Alternator size | Standard: 200 amp Optional: 250 amp |
| Battery options | 12 V |
| Working lights | Standard: 14 halogen Optional: 12 light-emitting diode (LED) plus two halogen |
| Type of bulb in headlight (Halogen, Zenon, LED) | Standard: 65-W halogen W Optional: LED |
