| Rated engine power | 280 kW 375 hp |
| Maximum engine power | 309 kW 415 hp |
| Solution system - Capacity | 6057 L 1600 gal. |
| Rinse tank capacity | 606 L 160 gal. |
| Boom length options/Material | Steel: 27.4, 30.5, or 36.6 m 90, 100, or 120 ft Carbon: 36.6 or 40.2 m 120 or 132 ft |
| Spray speed range | 0 to 40.2 km/h 0 to 25 mph |
| Transport speed, maximum | 56.3 km/h 35 mph |
| Suspension | Dual-strut independent wheel air-ride suspension |
| Crop clearance with standard tires | 147.3 cm 58 in. |
| Total weight (empty solution tank) | 17,225 kg 37,974 lb *Includes: 36.6-m (120-ft) steel boom, pressure recirculation, ExactApply™, and 38.1-cm (15-in.) spacing. Weight will vary depending on all options. |
| Emissions | Final Tier 4 (FT4) |
| Number of cylinders | Six |
| Displacement | 9.0 L 549 cu in. |
| Alternator | 250 amp |
| Fuel tank capacity | 565 L 149.2 gal. |
| Diesel exhaust fluid (DEF) tank capacity | 29.5 L 7.8 gal. |
| Capacity | 6057 L 1600 gal. |
| Tank material | Stainless steel |
| Quick fill size | 7.6 cm 3 in. |
| Automatic section control | John Deere Section Control (optional) |
| Solution system control | Manual Option: Automatic |
| Fill location | Side fill, front fill (optional), and LoadCommand (optional) |
| Chemical eductor | Stainless steel |
| Chemical eductor capacity (size) | 32 L 8.5 gal. |
| Flow meter size | 5.1 cm 2 in. |
| Suction strainer | 20 mesh |
| Pressure strainer | 50 mesh |
| Boom strainer | 80 mesh |
| Boom length options | Steel: 27.4, 30.5, or 36.6 m 90, 100, or 120 ft Carbon: 36.6 or 40.2 m 120 or 132 ft |
| Automatic boom height | BoomTrac Pro 2 - five sensor (optional) |
| Plumbing material | Stainless or polypropylene |
| Boom Material | Steel or carbon fiber |
| Ground height adjustment | 50 to 245 cm 19.6 to 96.5 in. |
| Breakaway width | Stainless-steel boom: 3.3 m 10.8 ft Carbon fiber boom: 3.7 m 12.1 ft |
| Boom sections | 13 sections with boom length: 40.2 m 132 ft 11 sections with boom length: 36.6 m 120 ft 9 sections with boom length: 30.5 m 100 ft 7 sections with boom length: 27.4 m 90 ft |
| Type | Hydrostatic |
| Drive | Full-time four-wheel drive (4WD) |
| Shifting | Electrohydraulic |
| Hydraulic reservoir capacity | 98.4 L 26 gal. |
| Dry compatible | Yes: 5.7 or 8.5 m 3 200 or 300 cu ft |
| Front tires | 380/105 R50, 420/95 R50, or 480/80 R50 |
| Rear tires | 380/105 R50, 420/95 R50, or 480/80 R50 |
| Flotation tires | 620/70 R46 or 800/55 R46 |
| Hydraulic tread adjust | Hydraulic |
| Wheel tread spacing | 305 to 406.4 cm 120 to 160 in. |
| Wheel base | 430 cm 169.3 in. |
| Turning radius | 9.2 m 30.2 ft |
| Parking brake | Spring-engaged, hydraulically disengaged wet disk pack |
