| Clearing width | Broom straight 52 in. 132 cm Broom angled 27 degrees: 48 in. 122 cm |
| Brush | Diameter 21 in. 53.3 cm Number of wafers 22 convoluted |
| Broom straight | 52 in. 132 cm |
| Broom angled | 27 degrees: 48 in. 122 cm |
| Diameter | 21 in. 53.3 cm |
| Material | Polypropylene |
| Number of wafers | 22 convoluted |
| Drive | Front power take-off (PTO) |
| Sweeping height | 9 positions in increments of 5 in. 13 mm |
| Speed | 220 rpm |
| Top speed | 1,209 fpm 369 m/min |
| Right and left | 0 to 27 degree (angle) |
| Housing | 14 gauge 0.07 in. 1.9 mm and 16 gauge 0.6 in. 15.5 mm steel |
| Frame | Plate: 0.25 in. 6 mm and tube steel: 1.5 in. |
| Lateral float | Hitch clearance |
| Input | Telescoping drive shaft |
| Center drive | Number 50 roller chain from offset 3:1 gearbox |
| Brush shaft | Oil-filled metal flange bearing and thrust bearing, greaseable |
| Size | With grease zerks: 6.25x3.25 in. 159x83 mm |
| Adjustment | Four spacer: 0.5 in. 13 mm |
| Storage stands | Standard equipment |
| Weight (broom only) | 240 lb 109 kg |
| Shipping weight | 306 lb 139 kg |
