| Model | Model year |
| 1775NT 2 Point | Model year 2018-current |
| 1775NT Drawbar | Model year 2018-current |
| DB60 36R | Model year 2018-Model year 2024 |
| DB90 36R | Model year 2018-Model year 2024 |
| All other DB's (except above) 36+ Rows | Model year 2018-current |
| All other DB's (except above) | Model year 2018-current |
| 1725C Mounted | Model year 2025-current |
| 1795 2 POINT HITCH | Model year 2018-current |
| 1795 DRAWBAR | Model year 2018-current |
| Number of rows | 20 |
| Row spacing | 51 cm 20 in. |
| Frame - Flexibility | Up and down: 15 degree (angle) |
| Row unit seed hoppers | Capacity 2.2 L 0.62 bu |
| Seed Meters | Base Vacuum |
| Flexibility | UP and down: 15 degree (angle) |
| Type | Wheel modules with rephasing hydraulic cylinders |
| Base | Wing tires: 7.50-20 6PR implement tire Center tires: VF295/75R22.5 |
| Opener | Tru-Vee™ double disk |
| Central Commodity System | Seed capacity Without liquid tank: 4581 L 130 bu With liquid tank: 3524 L 100 bu |
| Tank capacity | 1590 L 420 gal. |
| ExactRate Fluid Transfer System | Available |
| Transport width (with markers) | 4043 mm 159.2 in. |
| Transport length | 10425 mm 410.4 in. |
| Transport height | 4075 mm 160.4 in. |
| Field operation width | 13212 mm 520.2 in. |
| Field operation length | 7913 mm 311.5 in. |
| Recommended tractor horsepower | Minimum required for 9.1 m (30 ft) models: 201 kW 270 hp Minimum required for 12.2 m (40 ft) models: 268 kW 360 hp |
