| Model | Model year |
| 1775NT 2 Point | Model year 2018-current |
| 1775NT Drawbar | Model year 2018-current |
| DB60 36R | Model year 2018-Model year 2024 |
| DB90 36R | Model year 2018-Model year 2024 |
| All other DB's (except above) 36+ Rows | Model year 2018-current |
| All other DB's (except above) | Model year 2018-current |
| 1725C Mounted | Model year 2025-current |
| 1795 2 POINT HITCH | Model year 2018-current |
| 1795 DRAWBAR | Model year 2018-current |
| Number of rows | 12 |
| Row spacing | 76 cm 30 in. |
| Frame - Flexibility | Up and down: 21 degree (angle) |
| Row unit seed hoppers | Capacity 2.2 L 0.062 bu 58 L 1.65 bu 106 L 3.0 bu |
| Seed Meters | Base Vacuum Finger pickup Optional |
| Flexibility | Up and down: 21 degree (angle) |
| Type | Wheel modules with hydraulic cylinders |
| Base | Implement tire: VF245/70R19.5 |
| Optional | Factory-installed Soucy tracks |
| Opener | Tru-Vee double disk |
| Finger pickup | Optional |
| Radial bean meter | Optional |
| Central Commodity System | Seed capacity 3524 L 100 bu |
| Tank capacity | 1590 L 420 gal. |
| ExactRate Fluid Transfer System | Available |
| Transport width (with markers) | 3494 mm 137.56 in. |
| Transport length | 9197 mm 362 in. |
| Transport height | 3487 mm 137.3 in. |
| Field operation width | 9937 mm 391.2 in. |
| Field operation length | 6226 mm 245.1 in. |
| Recommended tractor horsepower | Minimum tractor size required: 90 kW 120 PTO hp Operating with extra planter attachments or when planting in soft seedbeds and rolling ground, more tractor power is required. |
