| Base Code | Description |
| 106PP | 1745 8Row 30 in. |
| 106RP | 1745 15Row 15 in. |
| 106SP | 1745 16Row 15 in. . |
| Number of rows | 8 |
| Row spacing | 76.2 cm (30 in.) |
| Frame - Fold configuration | Pivot fold |
| Frame - Flexibility | Rigid |
| Row unit seed hoppers | Capacity Mini, 56 L (1.6 bu), 106 L (3.0 bu) |
| Seed Meters | Base MaxEmerge™ 5 vacuum Optional Radial bean Finger pickup Yes |
| Fold configuration | Pivot fold |
| Frame tube size | 17.8 cm x 17.8 cm (7 in. x 7 in.) |
| Fold-and-go from tractor cab | Yes |
| Flexibility | Rigid |
| Base | Clevis drawbar |
| Optional | Ring style drawbar |
| Rear hitch | No |
| Type | Hydraulic frame lift |
| Number of cylinders | 1 |
| Quantity | 2 |
| Opener | Tru-Vee™ Double Disk |
| Depth gauging | 2 solid or spoked gauge wheels |
| Adjustment | Handle |
| Walking wheels | Yes |
| Row unit down force | Non-adjustable (4 springs) No Adjustable heavy-duty Yes Pneumatic Yes |
| Scrapers, opener blades | Plastic rotary No Steel straight blade Yes Heavy-duty Yes |
| Seed tube sensors | Base AccuCount™ |
| Finger pickup | Yes |
| Radial bean meter | Yes |
| Central Commodity System | Seed capacity 1762 L (50 bu) |
| Number of drive wheels | 1 |
| Drive wheel disconnect | When planter is raised |
| Control | Base Connected to planter lift Optional Independent of planter lift |
| Marker disk | Base 40.6 cm (16 in.) notched disk with depth gauging band |
| Shear bolt protection | Yes |
| Less marker option | Yes |
| Rubber tire closing system | Wheel 2 Position 4 slots Adjustment T handle Down force Spring Alignment In-line or staggered |
| Cast iron closing system | Wheel 2 Position 4 slots Adjustment In-line or staggered |
| Insecticide only hopper | Yes |
| System available | No |
| Unit-mounted coulter | Yes |
| Bubble blade | Yes |
| .63-in. fluted blade (25 flutes) | Yes |
| .7-in. fluted blade (13 flutes) | Yes |
| Row cleaner | Yes |
| Row cleaner - unit-mounted coulter | Yes |
| Onboard / towed / tractor tanks | 2-Onboard |
| Tank capacity | 1,136 L (300 gal) total |
Inventory moves fast. Call your nearest store to confirm this unit is still here and get the current price.
Yes. Send us the make, model, year and hours of your machine and we will apply the equity.
Often yes, through John Deere Financial and outside lenders depending on the machine. Subject to approved credit and to change.
Yes. We move equipment between all 17 of our Indiana and Ohio dealerships.
Tell us what you want to know about the John Deere 1745.
