| Base code | Description |
| 350UH | 1705 Integral Rigid 4Row 30, 36, 38, or 40 in. |
| 350VH | 1705 Integral Rigid 6Row 36, 38, or 40 in. |
| 350WH | 1705 Integral Rigid 8Row 30 in. |
| 350XH | 1705 Integral Rigid 8Row 36, 38, or 40 in. |
| Marker capabilities | Marker control |
| Automatic alternation as planter is lifted | X |
| Number of rows | 6 |
| Row spacing | 91, 97, and 102 cm 36, 38, and 40 in. |
| Row unit seed hoppers | Capacity 58 or 106 L 1.6 or 3 bu |
| Seed Meters | Base Vacuum |
| Type | Integral or semi-integral |
| Base | 7.60-15 6 Ply - Traction: 280 kPa 2.8 bar 40 psi 7.60-15 8 Ply - Traction: 359 kPa 3.6 bar 52 psi |
| Opener | Tru-Vee double disk |
| Transport width (with markers) | 7036 mm 277 in. |
| Transport width (without markers) | 5842 mm 230 in. |
| Transport length | 3378 mm 133 in. |
| Transport weight | 1490 kg 3280 lb |
| Recommended tractor horsepower | Hydraulic oil required to operate the planter: 5.7 L 1.5 gal. Hydraulic system working pressure: 20,684 kPa 207 bar 3000 psi Hydraulic system burst pressure: 82,737 kPa 827 bar 12,000 psi |
