| Engine power | 24 hp 17.9 kW |
| Engine manufacturer/model | 3TNM74F |
| Transaxle type | K90 hydrostatic integrated with transaxle |
| Transaxle control | Twin Touch™ pedals |
| Rear tires | 26x10.5-12 turf |
| Lift system type | Two-function hydraulic |
| Cutting width | Accel Deep™ mower deck, 48 in. 122 cm High capacity mower deck, 54, 60 in. 137, 152 cm |
| Power | 24 hp 17.9 kW |
| Displacement | 60.6 cu in. 993 cc |
| Manufacturer/model | 3TNM74F |
| Type | Diesel, overhead valve, full-pressure lube, oil filter |
| Cylinders | Three, cast-iron liners |
| Governor | Mechanical |
| Choke/speed control | One lever |
| Cooling method | Liquid |
| Air cleaner | Paper dry-type with primary and secondary elements |
| Oil change | No tools |
| Fuel delivery | In-line indirect injection |
| Fuel gauge | Gauge on dash |
| Fuel tank location | Rear |
| Fuel fill opening | On left fender, 3 in. 7.6 cm |
| Fuel tank capacity | 5.2 U.S. gal. 19.7 L |
| Battery | 12 V 500 CCA |
| Charging system | Engine-mounted alternator, regulated, 40 amp |
| Engine starter | Solenoid shift |
| Hour meter | Yes |
| Headlights | Two standard, halogen, 37 W |
| Taillights or reflector | Taillights |
| Backup lights | Yes |
| Rear work lights | Yes |
| 12-V outlet | Yes |
| Control | Twin Touch™ pedals |
| Cruise control | Yes |
| Oil cooler | Yes |
| Oil filter | Replaceable suction side 10 micron |
| Differential lock | Standard |
| Forward speed | 0-8.5 mph 0-13.7 km/h |
| Reverse speed | 0-6 mph 0-9.7 km/h |
| Brakes | Internal wet disc |
| Frame | Welded heavy-duty |
| Primer/paint | E-coat/powder |
| Weight bracket | Standard front - holds up to four Quik-Tatch weights, 42 lb 19 kg |
| Receiver hitch | Yes, front |
| Front axle | JDM BA8 nodular iron casting |
| Spindle bushings | Metal, replaceable |
| Front tires | 18x7-8 turf |
| Hood material | Noryl GTX902, painted |
| Fender deck material | Stamped steel |
