New
Grooming Mowers
John Deere FM40 Series
Request price
Available through TRULAND Equipment
- Category
- Grooming Mowers
- Type
- Grooming Mowers
- Condition
- New
| Cutting width - Total | 3.65 m 12 ft |
| Transport width | 2.4 m 7.75 ft |
| Cutting height- Range, in. (cm) | 3.8-11.4 cm 1.5-4.5 in. |
| Deck - Thickness, gauge | 10 gauge 3.416 mm 0.1345 in. |
| Discharge type | Rear |
| Caster wheels - Type | Solid |
| Hitch - Adjustment | Self-leveling, multi-position |
| Hitch - Drawbar | Category 1 |
| Power | 18.6-44.7 kW 25-60 hp |
| PTO speed rpm | 540 rpm |
| Total | 3.8 m 12.5 ft |
| Center deck | 1.4 m 4.5 ft |
| Wing deck | 1.4 m 4.5 ft |
| Overall width | 3.8 m 12.583 ft |
| Transport length | 3.2 m 10.5 ft |
| Max overall length | 3.4 m 11.25 ft |
| Transport height | 1.8 m 5.9 ft |
| Operating | 923.1 kg 2,035 lb |
| Shipping | 950.3 kg 2,095 lb |
| Operating tongue | 145.1 kg 320 lb |
| Transport tongue | 231.3 kg 510 lb |
| Ratio | 1-to-2.5 |
| Splitter gearbox | 74.6 kW 100 hp |
| Mower deck gearbox | 26.1 kW 35 hp |
| Type | Gearbox over V-belt |
| Wing driveline | Category 3 |
| Input driveline | Category 3 CV |
| Drawbar | Category 1 |
| Clevis | Floating |
| Adjustment | Self-leveling, multi-position |
| Thickness, gauge | 10 gauge 3.416 mm 0.1345 in. |
| Overlap | 15.2 cm 6 in. |
| Lift cylinders | 7.6x25.4 cm 3x10 in. |
| Wing travel, degrees | Up 20 degree (angle) and down 15 degree (angle) |
| Range, in. (cm) | 2.5-11.4 cm 1-4.5 in. |
| Average tip speed | 4,938 m/min 16,200 fpm |
| Spindle quantity | Nine |
| Spindle type | Cast iron |
| Spindle bearings | Greaseable ball |
| Dimensions, type 1 | 0.6x6.4 cm 0.25x2.5 in. |
| Composition | Heat-treated alloy steel |
| Transport | (2) 20X8-10 |
| Quantity | 10 |
| Size | 25.4x10.2 cm 10x4 in. |
| Bearings | Powder metal bushing |
| Front | Standard |
| Pounds per square inch (kg per square centimeter) | 5 pounds per square inch |
| Mainframe | 10.2 cm 4 in. |
