| Engine description | John Deere PowerTech™ PSS |
| Engine displacement | 6.8 L 415 cu in. |
| Rated engine power | 230 hp 169 kW |
| Maximum engine power | 253 hp 186 kW |
| Rated PTO power (hp SAE) | 184 hp 137 kW |
| Maximum PTO power | At 1000 PTO rpm: 150 kW 201 hp |
| Transmission type | Standard: Infinitely variable transmission (IVT™) 40 km/h Optional: IVT 50 km/h |
| Hydraulic pump rated output | Standard: 60-cc pump: 155 L/min 41 gpm Optional: 85-cc pump: 195 L/min 51 gpm |
| Rear hitch category (SAE designation) | 3N/3 |
| Base machine weight | 9600 kg 21,164 lb |
| Description | John Deere PowerTech™ PSS |
| Engine type | 6068HL550 |
| Rated speed | 2100 rpm |
| Aspiration | Dual turbochargers, variable geometry turbo with fixed geometry turbo in series |
| Emission level | Final Tier 4 |
| After treatment type | Diesel particle filter (DPF) with diesel oxidation catalyst (DOC) and selective catalytic reduction (SCR) using diesel exhaust fluid (DEF) |
| Displacement | 6.8 L 415 cu in. |
| Rated power | 230 hp 169 kW |
| Intelligent Power Management (IPM) | Transport and/or mobile PTO applications Additional engine power (hp ISO) at 2100 rpm: 14.9 kW 20 hp |
| Power boost | 10 percent |
| Engine peak torque | 1077 Nm |
| PTO torque rise | 40 percent |
| Type | Standard: Infinitely variable transmission (IVT™) 40 km/h Optional: IVT 50 km/h |
| Reverser | Electronic left-hand reverser |
| Creeper | Not available |
| Pump rated output | Standard: 60-cc pump: 155 L/min 41 gpm Optional: 85-cc pump: 195 L/min 51 gpm |
| Number of rear selective control valves (SCVs) | Standard: Two ISO couplers Optional: Two to four ISO couplers |
| Number of mid selective control valves (SCVs) | Up to three |
| Joystick SCV control | Mechanical/electrical |
| Remote control valves available | Standard |
| Hitch category (SAE designation) | 3N/3 |
| Rear hitch lift capacity (SAE designation) | Standard: Category 3/3N: 5900 kg 12,996 lb Optional: Category 3/3N: 6625 kg 14,593 lb |
| Maximum lift capacity behind lift points | Standard: Category 3/3N: 8800 kg 19,383 lb Optional: Category 3/3N: 9900 kg 21,806 lb |
| Sensing type | Electronic at lower link |
| Rear axle differential lock | Electrohydraulically with oil-cooled clutch |
| Drawbar category | Category 3 |
| Maximum vertical load | 1800-3000 kg (3968-6614 lb) Maximum vertical load dependent on drawbar position |
| Engine rpm (at rated PTO speeds) | 540 PTO: 1960 rpm 1000 PTO: 1960 rpm |
| PTO actuation | In-cab switch and optional external fender-mounted remote control |
| Category | 3N |
| Electric power | Seven-pin electrical socket |
| Standard lift capacity | At hook ends: 3300 kg 7269 lb |
| Front power take-off (PTO) | Electrohydraulically engaged with oil-cooled, multi-disc design |
| PTO speed | 1000 PTO: 1967 rpm |
| Rear differential lock | Electrohydraulically with oil-cooled clutch |
| Front axle differential lock | Standard: Self-locking differential Optional: hydrualic actuated |
| Front | 420/85R30 |
| Rear | 520/85R42 |
