| Engine description | John Deere PowerTech™ PVS |
| Engine displacement | 6.8 L 415 cu in. |
| Rated engine power | 200 hp 147 kW |
| Maximum engine power | 220 hp 162 kW |
| Rated PTO power (hp SAE) | 159 hp 118 kW |
| Maximum PTO power | At 1000 PTO rpm: 131 kW 176 hp |
| Hydraulic pump rated output | Standard: 45-cc pump: 114 L/min 30 gpm Optional: 60-cc pump: 155 L/min 41 gpm |
| Rear hitch category (SAE designation) | 3N/3 |
| Base machine weight | 8700 kg 19,180 lb |
| Description | John Deere PowerTech™ PVS |
| Engine type | 6068HL558 |
| Rated speed | 2100 rpm |
| Aspiration | Single variable geometry turbocharger |
| Emission level | Final Tier 4 |
| After treatment type | Diesel particle filter (DPF) with diesel oxidation catalyst (DOC) and selective catalytic reduction (SCR) using diesel exhaust fluid (DEF) |
| Displacement | 6.8 L 415 cu in. |
| Rated power | 200 hp 147 kW |
| Intelligent Power Management (IPM) | Transport and/or mobile PTO applications Additional engine power (hp ISO) at 2100 rpm: 14.9 kW 20 hp |
| Power boost | 10 percent |
| Engine peak torque | 936 Nm |
| PTO torque rise | 40 percent |
| Reverser | Electronic left-hand reverser |
| Creeper | Not available |
| Type | Standard/optional: Pressure-and-flow compensated (PFC) system with Load Sensing function |
| Pump rated output | Standard: 45-cc pump: 114 L/min 30 gpm Optional: 60-cc pump: 155 L/min 41 gpm |
| Number of rear selective control valves (SCVs) | Standard: Two ISO couplers Optional: Two to four ISO couplers |
| Number of mid selective control valves (SCVs) | Up to three |
| Joystick SCV control | Mechanical/electrical |
| Remote control valves available | Standard |
| Hitch category (SAE designation) | 3N/3 |
| Rear hitch lift capacity (SAE designation) | Standard: Category 3/3N: 4600 kg 10,132 lb Optional: Category 3/3N: 5151 kg 11,346 lb |
| Maximum lift capacity behind lift points | Standard: Category 3/3N: 8050 kg 17,731 lb Optional: Category 3/3N: 9050 kg 19,934 lb |
| Sensing type | Electronic at lower link |
| Rear axle differential lock | Electrohydraulically with oil-cooled clutch |
| Drawbar category | Category 3 |
| Maximum vertical load | 1800-3000 kg (3968-6614 lb) Maximum vertical load dependent on drawbar position |
| Engine rpm (at rated PTO speeds) | 540 PTO: 1960 rpm 1000 PTO: 1960 rpm |
| PTO actuation | In-cab switch and optional external fender-mounted remote control |
| Category | 3N |
| Electric power | Seven-pin electrical socket |
| Standard lift capacity | At hook ends: 3300 kg 7269 lb |
| Front power take-off (PTO) | Electrohydraulically engaged with oil-cooled, multi-disc design |
| PTO speed | 1000 PTO: 1969 rpm |
| Final drive type | Three planetary gear reduction |
| Rear differential lock | Electrohydraulically with oil-cooled clutch |
| Front axle differential lock | Standard: Self-locking differential Optional: hydrualic actuated |
| Front | 420/85R30 |
| Rear | 480/80R46 |
Inventory moves fast. Call your nearest store to confirm this unit is still here and get the current price.
Yes. Send us the make, model, year and hours of your machine and we will apply the equity.
Often yes, through John Deere Financial and outside lenders depending on the machine. Subject to approved credit and to change.
Yes. We move equipment between all 17 of our Indiana and Ohio dealerships.
Tell us what you want to know about the John Deere 6M 200.
