| Engine description | John Deere PowerTech™ PSS |
| Engine displacement | 4.5 L 275 cu in. |
| Rated engine power | 140 hp 103 kW |
| Maximum engine power | 154 hp 113 kW |
| Rated PTO power (hp SAE) | 111 hp 83 kW |
| Maximum PTO power | At 1000 PTO rpm with IPM: 96 kW 129 hp |
| Hydraulic pump rated output | Standard: 35-cc pump: 80 L/min 21 gpm Optional: 45-cc pump: 114 L/min 30 gpm |
| Rear hitch category (SAE designation) | 2/3N |
| Base machine weight | 6300 kg 13,889 lb |
| Description | John Deere PowerTech™ PSS |
| Engine type | 4045HL557 |
| Rated speed | 2100 rpm |
| Aspiration | Dual turbochargers, variable geometry turbo with fixed geometry turbo in series |
| Emission level | Final Tier 4 |
| After treatment type | Diesel particle filter (DPF) with diesel oxidation catalyst (DOC) and selective catalytic reduction (SCR) using diesel exhaust fluid (DEF) |
| Displacement | 4.5 L 275 cu in. |
| Rated power | 140 hp 103 kW |
| Intelligent Power Management (IPM) | Transport and/or mobile PTO applications Additional engine power (hp ISO) at 2100 rpm: 14.9 kW 20 hp |
| Power boost | 10 percent |
| Engine peak torque | 656 Nm |
| PTO torque rise | 40 percent |
| Reverser | Electronic left-hand reverser |
| Creeper | Optional |
| Type | Standard: Pressure compensated (PC) Optional: Pressure-and-flow compensated (PFC) system with Load Sensing function |
| Pump rated output | Standard: 35-cc pump: 80 L/min 21 gpm Optional: 45-cc pump: 114 L/min 30 gpm |
| Number of rear selective control valves (SCVs) | Standard: Two ISO couplers Optional: Two to four ISO couplers |
| Number of mid selective control valves (SCVs) | Up to three |
| Joystick SCV control | Mechanical/electrical |
| Remote control valves available | Standard |
| Hitch category (SAE designation) | 2/3N |
| Rear hitch lift capacity (SAE designation) | Standard: Category 2/3N: 3600 kg 7930 lb Optional: Category 2/3N: 4100 kg 9031 lb |
| Maximum lift capacity behind lift points | Standard: Category 2/3N: 5650 kg 12,445 lb Optional: Category 2/3N: 6400 kg 14,097 lb |
| Sensing type | Electronic at lower link |
| Rear axle differential lock | Electrohydraulically with oil-cooled clutch |
| Drawbar category | Category 2 |
| Maximum vertical load | 1200-2000 kg (2649-4409 lb) Maximum vertical load dependent on drawbar position |
| Engine rpm (at rated PTO speeds) | 540 PTO: 1977 rpm 1000 PTO: 1972 rpm |
| PTO actuation | In-cab switch and optional external fender-mounted remote control |
| Category | 3N |
| Electric power | Seven-pin electrical socket |
| Standard lift capacity | At hook ends: 3300 kg 7269 lb |
| Front power take-off (PTO) | Electrohydraulically engaged with oil-cooled, multi-disc design |
| PTO speed | 1000 PTO: 1969 rpm |
| Final drive type | Three planetary gear reduction |
| Rear differential lock | Electrohydraulically with oil-cooled clutch |
| Front axle differential lock | Self-locking differential |
| Front | 380/85R24 |
| Rear | 460/85R34 |
