| Engine description | John Deere PowerTech™ EWL |
| Engine displacement | 4.5 L 275 cu in. |
| Rated engine power | 81 kW 110 hp Rated Power with IPM: 96 kW 130 hp |
| Maximum engine power | 90 kW 122 hp w/ IPM: 98 kW 134 hp |
| Rated PTO power (hp SAE) | 62 kW 84 hp |
| Maximum PTO power | At 1000 PTO rpm with IPM: 80 kW 109 hp |
| Hydraulic pump rated output | Standard: 35-cc pump: 80 L/min 21 gpm Optional: 45-cc pump: 114 L/min 30 gpm |
| Rear hitch category (SAE designation) | 2/3N |
| Base machine weight | 5680 kg 12,522 lb |
| Description | John Deere PowerTech EWL |
| Engine type | 4045HL290 |
| Engine family | JDXL04.5317 |
| Rated speed | 2100 rpm |
| Aspiration | Single turbocharger with wastegate |
| Emission level | Final Tier 4 |
| After treatment type | Diesel oxidation catalyst (DOC) and selective catalytic reduction (SCR) using diesel exhaust fluid (DEF) |
| Displacement | 4.5 L 275 cu in. |
| Rated power | 81 kW 110 hp w/ IPM: 96 kW 130 hp |
| Power boost | 10 percent |
| Engine peak torque | At 1600 U/min: 515 Nm 379.84 lb-ft |
| PTO torque rise | 40 percent |
| Reverser | Electronic left-hand reverser |
| Creeper | Optional |
| Type | Standard: Pressure compensated (PC) Optional: Pressure-and-flow compensated (PFC) system with Load Sensing function |
| Pump rated output | Standard: 35-cc pump: 80 L/min 21 gpm Optional: 45-cc pump: 114 L/min 30 gpm |
| Number of rear selective control valves (SCVs) | Standard: Two ISO couplers Optional: Two to four ISO couplers |
| Number of mid selective control valves (SCVs) | Up to three |
| Joystick SCV control | Mechanical/electrical |
| Remote control valves available | Standard |
| Hitch category (SAE designation) | 2/3N |
| Maximum lift capacity behind lift points | Standard: 3750 kg 8267.3 lb Optional: 5000 kg 11,023.1 lb |
| Sensing type | Electronic lower link |
| Rear axle differential lock | Electrohydraulically with oil-cooled clutch |
| Drawbar category | Category 2 |
| Maximum vertical load | Road/field use (250-mm extended): 2000 kg 4409.2 lb Field use (350-mm extended): 1400 kg 3086.5 lb Field use (400-mm extended): 1200 kg 2645.5 lb |
| Engine rpm (at rated PTO speeds) | 540: 1977 rpm 1000: 1972 rpm |
| PTO actuation | In-cab switch and external fender-mounted remote control |
| Category | 3N |
| Electric power | Seven-pin electrical socket |
| Standard lift capacity | 4400 kg 9700.3 lb |
| Front power take-off (PTO) | Electrohydraulically engaged with oil-cooled, multi-disc design |
| PTO speed | 1000 PTO: 1969 rpm |
| Final drive type | Three planetary gear reduction |
| Rear differential lock | Electrohydraulically with oil-cooled clutch |
| Front axle differential lock | Self-locking differential |
| Rear | 600/65R38 (175) |
| Alternator size | Standard: 14 V/120 amp Optional: 14 V/150 amp 14 V/200 amp |
| Battery options | Standard: 12 V/154 amp-hr Optional: 12 V/174 amp-hr |
