| Engine description | John Deere PowerTech™ 4045 EWL |
| Engine displacement | 4 cylinder: 4.5 L 276 cu in. |
| Rated engine power | At 2200 rpm: 95.8 kW 130 hp |
| Maximum engine power | 99.9 kW 133.9 hp |
| Rated PTO power (hp SAE) | At 2100 rpm: 84.5 kW 115 hp |
| Transmission type | Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R Powr8™ 32F/16R with creeper |
| Hydraulic pump rated output | 97 L/min 25.6 gpm |
| Rear hitch category (SAE designation) | Category 2; convertible to 1 |
| Base machine weight | 3964 kg (8,740 lb) |
| Description | John Deere PowerTech™ 4045 EWL |
| Engine type | 4045HLV82 |
| Engine family | NJDXL04.5317 |
| Rated speed | 2200 rpm |
| Aspiration | Turbocharged/air-to-air aftercooled |
| Cylinders liners | Wet sleeved |
| Emission level | Final Tier 4 |
| After treatment type | DOC/SCR |
| Displacement | 4 cylinder: 4.5 L 276 cu in. |
| Rated power | At 2200 rpm: 95.8 kW 130 hp |
| Power boost | At 1900 rpm: 4 percent |
| Engine peak torque | At 1600 rpm: 541 Nm 399 lb-ft |
| PTO torque rise | At 1600 rpm: 30 percent |
| Type | Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R Powr8™ 32F/16R with creeper |
| Reverser | Left hand, electrohydraulic |
| Clutch; wet/dry | Wet |
| Creeper | Powr8™ 32F/16R with creeper |
| Pump rated output | 97 L/min 25.6 gpm |
| Available flow at a single rear SCV | 73 L/min 19.3 gpm |
| Number of rear selective control valves (SCVs) | Standard: Two Optional: Three |
| Number of mid selective control valves (SCVs) | Standard: Two Optional: Up to Three |
| Joystick SCV control | Mechanical |
| Hitch draft control load sense type | Electrohydraulic |
| Remote control valves available | Standard: Two Optional: Three |
| Hitch category (SAE designation) | Category 2; convertible to 1 |
| Maximum lift capacity behind lift points | Standard: 3164 kg 6975 lb Optional: 3569 kg 7868 lb |
| Sensing type | Lower link |
| Rear axle differential lock | Electrohydraulic |
| Drawbar category | Category 2 |
| Maximum vertical load | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg 2646 lb |
| Engine rpm (at rated PTO speeds) | 540 at 2100 rpm 540E at 1645 rpm 1000 at 2100 rpm |
| PTO actuation | Electrohydraulic |
| Category | Category 2 |
| Standard lift capacity | 1931 kg 4257 lb |
| Front power take-off (PTO) | 1000 rpm (21 spline) 34.9 mm (1.375 in.) |
| PTO speed | 1000 at 2200 rpm |
| Final drive type | Inboard planetary |
| Differential controls | Electrohydraulic |
| Brakes, type and control | Hydraulic wet disc |
