| Engine description | John Deere PowerTech™ 4045 PWL |
| Engine displacement | 4 cylinders: 4.5 L 276 cu in. |
| Rated engine power | At 2400 rpm: 67.1 kW 90 hp |
| Maximum engine power | 68.6 kW 92 hp |
| Rated PTO power (hp SAE) | At 2400 rpm: 56.0 kW 75 hp |
| Transmission type | Standard: PowrReverser™ 12F/12R Optional: PowrReverser™ Hi-Lo 24F/12R |
| Hydraulic pump rated output | 85.1 L/min 22.5 gpm |
| Rear hitch category (SAE designation) | Category 2 |
| Description | John Deere PowerTech 4045 PWL |
| Engine type | 4045HLV76 |
| Engine family | NJDXL04.5315 |
| Rated speed | 2400 rpm |
| Aspiration | Turbocharged and Aftercooled |
| Cylinders liners | Wet sleeved |
| Emission level | Final Tier 4 |
| After treatment type | DOC/SCR |
| Displacement | 4 cylinders: 4.5 L 276 cu in. |
| Rated power | At 2400 rpm: 67.1 kW 90 hp |
| Power boost | At 2200 rpm: 2 percent |
| Engine peak torque | At 1600 rpm: 347 Nm 255 lb-ft |
| Type | Standard: PowrReverser™ 12F/12R Optional: PowrReverser™ Hi-Lo 24F/12R |
| Reverser | Yes |
| Clutch; wet/dry | Wet |
| Creeper | Not available |
| Pump rated output | 85.1 L/min 22.5 gpm |
| Available flow at a single rear SCV | 60.1 L/min 15.9 gpm |
| Number of rear selective control valves (SCVs) | Standard: Two Optional: Three |
| Number of mid selective control valves (SCVs) | Standard: Zero Optional: Up to Three |
| Joystick SCV control | Mechanical |
| Hitch draft control load sense type | Mechanical |
| Remote control valves available | Standard: Two Optional: Three |
| Hitch category (SAE designation) | Category 2; convertible to 1 |
| Maximum lift capacity behind lift points | Standard: 2100 kg 4600 lb |
| Sensing type | Top link |
| Drawbar category | Category 2 |
| Maximum vertical load | Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg |
| Engine rpm (at rated PTO speeds) | 540 at 2400 rpm 540E at 1716 rpm 1000 at 2400 rpm |
| PTO actuation | Electrohydraulic |
| Final drive type | Inboard planetary |
| Differential controls | Mechanical (pedal) |
| Brakes, type and control | Hydraulic wet disc |
| Rear | MFWD: 18.4-30 R1 Bias |
| Wheel tread range | MFWD: front: 1340-1904 mm 52.8-75.0 in. |
| Turning radius with brakes | MFWD: 4.36 m 14.3 ft |
| Turning radius without brakes | MFWD: 3.54 m 11.6 ft |
| Alternator size | OOS: 90 amp Cab: 120 amp |
| Battery options | 12 V |
| Working lights | Halogen |
