| Features | Standard Cab Premium Panorama Roof Cab |
| Deluxe isolated cab with flat floor | X X |
| Tilt and telescopic steering column | X X |
| Convenience power outlet | X X |
| Air conditioning and heater | X X |
| Speedometer | X X |
| Beverage Holder | X X |
| Sun visor for front window | X X |
| Two-speed front windshield wiper and washer | X X |
| Two front/two rear roof-mounted worklights | X X |
| Two front/two rear roof-mounted warning lights | X X |
| Two fender-mounted taillights | X X |
| 120Amp Alternator | X X |
| Monitor mounting bosses (two Sets) | X X |
| Right-hand console light | X X |
| Radio preparation (with speakers, wiring) | X X |
| Rear window grab handle | X X |
| Bluetooth® ready | X X |
| Requires option code 3025 (Deluxe cornerpost exhaust). | X X |
| Fixed panorama roof with shade | - X |
| Radio (Bluetooth® Capable) | Option X |
| Rear window wiper | Option X |
| Radio antenna | - X |
| Transmission | Cylinder diameter Lift capacity at 610-mm (24-in) behind lift point |
| PowrReverser™ transmission models | Two 65-mm (2.56-in.) cylinders See specifications for lift capacity. |
| PowrReverser models with optional high-capacity hitch | One 65-mm (2.56-in.) cylinder One 75-mm (2.95-in.) cylinder |
| PowrQuad PLUS or Powr8 transmission models | Two 75-mm (2.95-in.) cylinders |
| Model | Cylinders Engine displacement Engine hp PTO hp Rated rpm Aspiration |
| 5075M | 3 2.9 L (0.77 gal.) 75 57.6 2400 Turbocharged |
| Engine displacement | 3 cylinder: 2.9 L 179 cu in. |
| Rated engine power | At 2200 rpm: 55.1 kW 75 hp |
| Maximum engine power | 55.1 kW 75 hp |
| Rated PTO power (hp SAE) | At 2100 rpm: 43 kW 57.7 hp |
| Transmission type | Standard: PowrReverser™ 16F/16R Optional: PowrReverser Hi-Lo 32F/16R |
| Hydraulic pump rated output | 94 L/min 24.7 gpm |
| Rear hitch category (SAE designation) | Category 2; convertible to 1 |
| Description | John Deere PowerTech™ 3029 EWX |
| Engine type | 3029HPY96 |
| Engine family | NJDXL02.9318 |
| Rated speed | 2200 rpm |
| Aspiration | Turbocharged and air-to-air aftercooled |
| Cylinders liners | Wet sleeved |
| Emission level | Final Tier 4 |
| After treatment type | DOC/DPF |
| Displacement | 3 cylinder: 2.9 L 179 cu in. |
| Rated power | At 2200 rpm: 55.1 kW 75 hp |
| Power boost | 0 percent |
| Engine peak torque | At 1600 rpm: 300 Nm 221 lb-ft |
