| Sunroof with sunshade | NA Included |
| USB and auxiliary audio port | NA Included |
| Rear window pull handle | NA Included |
| Instructional seat | Optional Included |
| Air ride suspension seat with swivel | Optional Included |
| Bluetooth radio with microphone | Optional Included |
| Two rear SCVs | Optional Included |
| Rear window wiper with washer | Optional Included |
| Right-hand door and steps | Field kit Included |
| Tilt and telescopic steering column | Included Included |
| Air conditioning and heater | Included Included |
| Convenience power outlet | Included Included |
| LED headlights (high and low beam) | Included Included |
| Three-position (on/off/auto) interior dome light | Included Included |
| Right-hand console ambient lighting | Included Included |
| Beverage holders | Included Included |
| Sun visor | Included Included |
| Rearview mirror | Included Included |
| Two mounting bosses for monitors or accessories on B-pillar | Included Included |
| Radio Preparation (with speakers and wiring) | Included Radio preparation with Bluetooth radio |
| Front windshield wiper with washer | Included Included |
| Amp-style, three-socket power connector | Included Included |
| Stationary PTO enable switch | Included Included |
| Go home lighting | Included Included |
| Option code | Description Applicable Models |
| 1520 | eHydro™ Transmission 5060E, 5067E, 5075E |
| Two headlights (high and low beam) | LED LED LED |
| One rear worklight | LED --- --- |
| Two front and two rear worklights | --- LED LED |
| Amber turn signal/flashing warning lights | Two rollover protective structure (ROPS)-mounted Two forward and two rear roof-mounted Two forward and two rear roof-mounted |
| Two rear taillights | X X X |
| Right-hand Console ambient lighting | --- X X |
| Three-position dome light (on/off/auto) | -- X X |
| Go-home lighting | --- X X |
| Engine Make | John Deere |
| Engine Model | John Deere PowerTech™ 3029 EWR |
| Engine Family | NJDXL02.9339 |
| Displacement (L) | 3 cylinders: 2.9 L |
| Displacement (cu in.) | 3 cylinders: 179 cu in. |
| Rated Engine Power (hp) | 71.3 hp @2100 rpm |
| Rated Engine Power (kw) | 53.2 kW @2100 rpm |
| Transmission Type | Standard: SyncShuttle 9F/3F; Optional: PowrReverser 12F/12R; Optional: eHydro™ |
| Rear Hitch Category (SAE Designation) | Category 2; convertible to 1 |
| Pump Rated Output | 18.2 gpm (68.6 L/min) - PR/TSS (2 Pumps Engine Mouted) 29.6 gpm (112 L/min) - HST (3 Pumpes (2 Engine moutned and 1 Drive Train Mounted) |
| Base Machine Weight (lb) | 2WD OOS: 5,445 lb 2WD Cab: 6,480 lb MFWD OOS: 5,919 lb MFWD Cab: 6,702 lb |
| Base Machine Weight (kg) | 2WD OOS: 2,470 kg 2WD Cab: 2,939 kg MFWD OOS: 2,685 kg MFWD Cab: 3,040 kg |
| Wheel or Track Configuration | wheel |
| Drive Type | Planetary |
