| Two headlights (high and low beam) | LED LED LED |
| One rear worklight | LED --- --- |
| Two front and two rear worklights | --- LED LED |
| Amber turn signal/flashing warning lights | Two rollover protective structure (ROPS)-mounted Two forward and two rear roof-mounted Two forward and two rear roof-mounted |
| Two rear taillights | X X X |
| Right-hand Console ambient lighting | --- X X |
| Three-position dome light (on/off/auto) | -- X X |
| Go-home lighting | --- X X |
| Engine Make | John Deere |
| Engine Model | John Deere PowerTech™ 3029 EWR |
| Engine Family | NJDXL02.9339 |
| Displacement (L) | 3 cylinders: 2.9 L |
| Displacement (cu in.) | 3 cylinders: 179 cu in. |
| Rated Engine Power (hp) | 50.1 hp @2100 rpm |
| Rated Engine Power (kw) | 37.4 kW @2100 rpm |
| Transmission Type | SyncShuttle 9F/3R |
| Rear Hitch Category (SAE Designation) | Category 2; convertible to 1 |
| Pump Rated Output | 18.2 gpm (68.6 L/min) --- TSS (2 Pumps Engine Mouted) |
| Base Machine Weight (lb) | 2WD OOS: 5,335 lb MFWD: 5,809 lb |
| Base Machine Weight (kg) | 2WD OOS: 2,420 kg MFWD: 2,634 kg |
| Wheel or Track Configuration | wheel |
| Drive Type | Planetary |
| Emissions Certifications | Final Tier 4 |
| Aspiration | Turbocharged |
| Number of Cylinders | 3 cylinders |
| Cylinder Liners | Wet sleeved |
| Aftertreatment Type | DOC/EGR |
| Rated Engine Speed (rpm) | 2100 rpm |
| Rated Engine Power (kW) | 37.4 kW @2100 rpm |
| Fuel Type | Diesel |
| Torque Rise (%) | 22% |
| Creeper | KIT AVAILABLE |
| Clutch | DRY |
| PTO Category | INDEPENDENT 540 |
| Rated PTO Power (hp) | 38 hp @2100 rpm |
| Rated PTO Power (kW) | 28.3 kW @2100 rpm |
| Economy PTO Speeds | 540 |
| Engine rpm at Rated PTO Speeds (540/1.000) | 2100 |
| Engagement Method | MECHANICAL LEVER |
| Maximum Lift Capacity at 610-mm Behind Hitch Point | 3,192 lb (1,448 kg) |
| Sensing Type | Top link |
| Draft Control Sensing | Mechanical |
| Drawbar Category | BASIC DRAWBAR |
| Maximum Vertical Load | Road/field use (short position): 1120 kg 2470 lb Field use (fully extended): 760 kg 1675 lb |
| Hydraulic System Type | OPEN CENTER |
| Number of Rear Selective Control Valves (SCVs) | Standard: one; Optional: two |
| Available Flow at a Single Rear SCV | 43.1 L/min 11.4 gpm |
| Hydraulics Number of Mid Selective Control Valves (SCVs) | Standard: zero; Optional up to three |
